Uni-T UT256 clamp meter
The Uni-T UT256 is a compact True RMS clamp meter designed for convenient measurement of AC and DC currents up to 60 A without the need to disconnect the circuit. Its slim design and 10 mm jaw opening make it easy to work in tight switchgear and hard-to-reach areas, making the device ideal for service and diagnostic work. An additional advantage is the built-in NCV sensor at the tip of the jaw, which enables non-contact voltage detection and increases safety during operation.
Practical features and ease of use
The UT256 model is equipped with Data Hold, Relative, and Zero functions, which facilitate measurements and result analysis. True RMS technology ensures greater accuracy when measuring AC signals, and the backlit screen improves readability in dimly lit areas. An audible and visual alarm enhances safety, while the auto-off feature helps conserve energy. Weighing just 120 g, with compact dimensions of 171 × 42 × 28 mm, and powered by two AAA batteries, this meter is a convenient tool for daily field work.
Included
- Clamp meter
- Test leads (1 pair)
- 2 AAA batteries
- Lanyard
- Carrying case
- User manual
Specifications
| Manufacturer | Uni-T |
|---|---|
| Model | UT256 |
| Product type | True RMS digital clamp meter |
| AC current range | 60 A ±(2% + 5) |
| DC current range | 60 A ±(2% + 5) |
| Maximum display reading | Auto range |
| Functions | True RMS, NCV, Data Hold, Relative mode, Zero mode, backlight, audible and visual alarm, auto power-off, low battery indicator |
| Jaw opening | 10 mm |
| Measurement category | CAT III 600V |
| Power supply | 2 × 1.5 V AAA batteries |
| Dimensions | 171 × 42 × 28 mm |
| Weight | 120 g |
| Color | Red and gray |
| Certifications | CE, UKCA, cETLus |
