Description
The quad-core 1.7 GHz TS-832PX features eight 3.5-inch SATA 6 Gb/s drive bays, providing ample storage capacity for a wide range of applications and everyday use. With two 10GbE SFP+ and two 2.5GbE network ports, the TS-832PX supports next-generation networking to enhance bandwidth-intensive applications and deliver smoother file access and sharing. It also supports various PCIe cards, including QM2 cards that provide M.2 SATA/NVMe SSD caching and Qtier™ auto-tiering storage to boost NAS performance.
Low power quad-core processor
Powered by a 64-bit quad-core ARM Cortex-A57 1.7 GHz processor and 4 GB of DDR4 RAM (expandable up to 16 GB), the TS-832PX features highly energy-efficient functionality without affecting system or application performance.
High-speed 10GbE and 2.5GbE connectivity
The TS-832PX features two 10GbE SFP+ and two 2.5GbE RJ45 ports, providing direct support for high-speed networking and supporting port trunking and failover to enhance your network infrastructure. In addition, QNAP offers a wide range of other high-speed networking solutions, including 10GbE/2.5GbE managed and unmanaged switches and network adapters, allowing you to establish a high-speed network environment at an affordable price.
Enhance the NAS's functionality with a PCIe card
Thanks to a PCIe Gen 2.0 slot, the TS-832PX offers flexibility for expanding NAS functionality and potential applications. To optimize system performance, install a QNAP QM2 card for 10GbE connectivity/M.2 SATA/NVMe SSD caching and use it with Qtier for peak system performance. Similarly, you can use a QNAP Wi-Fi 6 (802.11AX) network card to create a wireless environment. Additional options include QXG 5GbE/2.5GbE network adapter cards and USB 3.2 Gen 2 (10Gbps) cards. All these options ensure the TS-832PX can be upgraded to meet future requirements.
Protect important data with snapshots
Snapshots record the entire state and metadata of the NAS system and can be used to quickly restore files to their previously saved states if they are accidentally deleted or modified, or if the system is compromised by ransomware. QNAP snapshots are block-based and only record changed data. This not only saves storage space but also reduces the time required to back up and restore data. The TS-832PX supports up to 256 snapshots per NAS and up to 64 snapshots per volume or LUN.
Backup, access and synchronization of files Multipoint
The TS-832PX supports file-sharing protocols (including SMB/CIFS, AFP, and NFS) for Windows©, Mac©, and Linux©/UNIX© devices. Combined with Qsync (a utility that transforms a QNAP NAS into a secure, high-capacity data center for file synchronization), any file uploaded to the TS-832PX becomes available to all connected devices, such as desktops, laptops, and mobile devices. Hybrid Backup Sync helps you easily back up or synchronize data from the TS-832PX to another QNAP NAS, a remote server, or cloud storage (including Microsoft OneDrive©, Google Drive™, and Dropbox©) for disaster recovery.
AI-powered intelligent photo management
QuMagie integrates QuMagie Core AI image recognition technology for facial recognition, subject identification, and photo geotagging. Similar photos are categorized into People, Objects, and Places albums. QuMagie also includes a built-in timeline, customizable folder covers, iOS© Live Photo display, and a powerful search tool, providing you with the perfect photo management and sharing solution.
Access to cloud data with low latency via cloud storage gateways
By deploying cloud storage gateways and enabling local caching on the TS-832PX, you can perfectly utilize the cloud for data storage, backup, and restoration with low-latency access, thus providing an innovative hybrid cloud experience.
HybridMount File-Based Cloud Gateway
Flexibly expand your storage capacity by connecting to cloud storage. You can leverage QTS apps to manage and edit your cloud files or monitor multimedia files. HybridMount is ideal for online collaboration across file servers and for file-level data analysis.
VJBOD Cloud Block-based cloud gateway
VJBOD Cloud supports backing up data from your NAS to block-based cloud storage. Block-based data transmission transfers random data and large files to the cloud in blocks. Furthermore, it transmits only block-based volume or LUN changes. This is ideal for backing up LUNs, databases, and sensitive files.
Easily find and automatically organize files
The TS-832PX offers superior file management convenience. Using Qsirch, you can quickly find files and automatically archive them with Qfiling.
File search
Qsirch quickly finds images, music, videos, documents, emails and other files using keywords, colors and various filters.
Automatic archiving
Qfiling automates the organization or recycling of files based on self-configured rules, which greatly improves work efficiency.
Secure remote access to your QNAP NAS
Use myQNAPcloud Link to access, share, download, and manage files stored on a headquarters NAS over the internet. The QNAP NAS also supports VPN services, allowing remote workers to access the NAS and its resources on a private network from the internet. Alternatively, you can use QVPN Device Client, powered by QNAP's proprietary QBelt protocol, to easily connect to your TS-832PX and utilize measurement tools to monitor your VPN connection speeds and view connection history.
Flexible and economical storage expansion
QNAP provides several ways to increase the storage capacity of the TS-832PX to accommodate data growth:
- Upgrade the RAID capacity
Hot-swap smaller capacity disks for larger capacity disks to expand the TS-832PX.
- Add expansion boxes
Connect two expansion enclosures (TR-004 with 4 bays, TR-002 with 2 bays) or one TL-D800C with 8 bays, TL-D400S with 4 bays, TL-D800S with 8 bays and use the Storage and Snapshots Manager to manage the NAS capacity expansion.
- Migrate to a new NAS
Install your NAS hard drives on a larger QNAP NAS and retain all your existing data and configurations.
Boost your productivity
QVR Pro
Establish a secure surveillance environment with no additional software required. Provides free built-in channels, and you can also purchase QVR Pro licenses to deploy a large-scale surveillance network.
Notification Center
Consolidates all QTS system events, alerts and notifications for simple NAS management, keeping you always informed of your NAS status.
Security Counselor
A security portal to check for vulnerabilities and offer recommendations to improve NAS security. It also includes antivirus and anti-malware scanning software.
Low power quad-core processor
Powered by a 64-bit quad-core ARM Cortex-A57 1.7 GHz processor and 4 GB of DDR4 RAM (expandable up to 16 GB), the TS-832PX features highly energy-efficient functionality without affecting system or application performance.
High-speed 10GbE and 2.5GbE connectivity
The TS-832PX features two 10GbE SFP+ and two 2.5GbE RJ45 ports, providing direct support for high-speed networking and supporting port trunking and failover to enhance your network infrastructure. In addition, QNAP offers a wide range of other high-speed networking solutions, including 10GbE/2.5GbE managed and unmanaged switches and network adapters, allowing you to establish a high-speed network environment at an affordable price.
Enhance the NAS's functionality with a PCIe card
Thanks to a PCIe Gen 2.0 slot, the TS-832PX offers flexibility for expanding NAS functionality and potential applications. To optimize system performance, install a QNAP QM2 card for 10GbE connectivity/M.2 SATA/NVMe SSD caching and use it with Qtier for peak system performance. Similarly, you can use a QNAP Wi-Fi 6 (802.11AX) network card to create a wireless environment. Additional options include QXG 5GbE/2.5GbE network adapter cards and USB 3.2 Gen 2 (10Gbps) cards. All these options ensure the TS-832PX can be upgraded to meet future requirements.
Protect important data with snapshots
Snapshots record the entire state and metadata of the NAS system and can be used to quickly restore files to their previously saved states if they are accidentally deleted or modified, or if the system is compromised by ransomware. QNAP snapshots are block-based and only record changed data. This not only saves storage space but also reduces the time required to back up and restore data. The TS-832PX supports up to 256 snapshots per NAS and up to 64 snapshots per volume or LUN.
Backup, access and synchronization of files Multipoint
The TS-832PX supports file-sharing protocols (including SMB/CIFS, AFP, and NFS) for Windows©, Mac©, and Linux©/UNIX© devices. Combined with Qsync (a utility that transforms a QNAP NAS into a secure, high-capacity data center for file synchronization), any file uploaded to the TS-832PX becomes available to all connected devices, such as desktops, laptops, and mobile devices. Hybrid Backup Sync helps you easily back up or synchronize data from the TS-832PX to another QNAP NAS, a remote server, or cloud storage (including Microsoft OneDrive©, Google Drive™, and Dropbox©) for disaster recovery.
AI-powered intelligent photo management
QuMagie integrates QuMagie Core AI image recognition technology for facial recognition, subject identification, and photo geotagging. Similar photos are categorized into People, Objects, and Places albums. QuMagie also includes a built-in timeline, customizable folder covers, iOS© Live Photo display, and a powerful search tool, providing you with the perfect photo management and sharing solution.
Access to cloud data with low latency via cloud storage gateways
By deploying cloud storage gateways and enabling local caching on the TS-832PX, you can perfectly utilize the cloud for data storage, backup, and restoration with low-latency access, thus providing an innovative hybrid cloud experience.
HybridMount File-Based Cloud Gateway
Flexibly expand your storage capacity by connecting to cloud storage. You can leverage QTS apps to manage and edit your cloud files or monitor multimedia files. HybridMount is ideal for online collaboration across file servers and for file-level data analysis.
VJBOD Cloud Block-based cloud gateway
VJBOD Cloud supports backing up data from your NAS to block-based cloud storage. Block-based data transmission transfers random data and large files to the cloud in blocks. Furthermore, it transmits only block-based volume or LUN changes. This is ideal for backing up LUNs, databases, and sensitive files.
Easily find and automatically organize files
The TS-832PX offers superior file management convenience. Using Qsirch, you can quickly find files and automatically archive them with Qfiling.
File search
Qsirch quickly finds images, music, videos, documents, emails and other files using keywords, colors and various filters.
Automatic archiving
Qfiling automates the organization or recycling of files based on self-configured rules, which greatly improves work efficiency.
Secure remote access to your QNAP NAS
Use myQNAPcloud Link to access, share, download, and manage files stored on a headquarters NAS over the internet. The QNAP NAS also supports VPN services, allowing remote workers to access the NAS and its resources on a private network from the internet. Alternatively, you can use QVPN Device Client, powered by QNAP's proprietary QBelt protocol, to easily connect to your TS-832PX and utilize measurement tools to monitor your VPN connection speeds and view connection history.
Flexible and economical storage expansion
QNAP provides several ways to increase the storage capacity of the TS-832PX to accommodate data growth:
- Upgrade the RAID capacity
Hot-swap smaller capacity disks for larger capacity disks to expand the TS-832PX.
- Add expansion boxes
Connect two expansion enclosures (TR-004 with 4 bays, TR-002 with 2 bays) or one TL-D800C with 8 bays, TL-D400S with 4 bays, TL-D800S with 8 bays and use the Storage and Snapshots Manager to manage the NAS capacity expansion.
- Migrate to a new NAS
Install your NAS hard drives on a larger QNAP NAS and retain all your existing data and configurations.
Boost your productivity
QVR Pro
Establish a secure surveillance environment with no additional software required. Provides free built-in channels, and you can also purchase QVR Pro licenses to deploy a large-scale surveillance network.
Notification Center
Consolidates all QTS system events, alerts and notifications for simple NAS management, keeping you always informed of your NAS status.
Security Counselor
A security portal to check for vulnerabilities and offer recommendations to improve NAS security. It also includes antivirus and anti-malware scanning software.
| storage media | |
| Installed storage drives | No |
| Total installed storage capacity | 0 TB |
| Number of storage drives installed | 0 |
| Number of storage units supported | 8 |
| Type of storage drive installed | No |
| Supported storage drive types | HDD & SSD |
| Storage drive capacity | 0 GB |
| Interface for storage unit | ATA Series III |
| RAID support | Yes |
| Supported storage drive interfaces | ATA Series II, ATA Series III |
| Supported storage disk sizes | 2.5, 3.5" |
| RAID Levels | 0, 1, 5+S, 5, 6, 6+HS, 10+HS, 10, 50, 60, JBOD |
| Online RAID Migration | Yes |
| Online RAID expansion | Yes |
| RAID Reconstruction | Yes |
| Hot-swappable enclosure bays | Yes |
| Supported file systems | FAT32, HFS+, ext3, ext4 |
| Faulty block scan | Yes |
| Disk roaming | Yes |
| Processor | |
| Processor family | Annapurna Labs |
| Processor manufacturer | Annapurna Labs |
| Processor model | AL324 |
| Processor frequency | 1.7 GHz |
| Number of processor cores | 4 |
| The processor architecture | ARM Cortex-A57 |
| Number of processors supported | 1 |
| Memory | |
| Internal memory | 4GB |
| Internal memory type | DDR4 |
| Memory frequency | 2400 MHz |
| Maximum RAM supported | 16 GB |
| Memory locations | 1 |
| Memory support | SO-DIMM |
| Flash memory | 512 MB |
| Network | |
| Ethernet/LAN | Yes |
| Ethernet LAN: data transfer rate | 100, 1000, 2500, 10000 Mbit/s |
| DHCP Client | Yes |
| DHCP Server | Yes |
| Support for Jumbo Frames | Yes |
| iSCSI support | Yes |
| Wake-on-LAN ready | Yes |
| Link aggregation | Yes |
| Load balancing system | Yes |
| Dynamic DNS (DDNS) | Yes |
| WLAN adapter supported | Yes |
| Connectivity | |
| Number of LAN ethernet ports (RJ-45) | 2 |
| USB port | Yes |
| Number of USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports | 3 |
| Fibre Channel Ports | 2 |
| Fiber optic connector | SFP+ |
| Design | |
| Chassis type | Tower |
| Cooling type | Active |
| Product color | Aluminum, Black |
| Number of fans | 3 fan(s) |
| Fan diameter | 12 cm |
| Fan diameter 2 | 6 cm |
| Locking mechanism | Yes |
| Psychics | HDD, LAN, Status, System, USB |
| Anti-theft cable port | Yes |
| Cable lock location type | Kensington |
| representation / realization | |
| Kind | NAS |
| Device class | SMEs |
| Backup function | Yes |
| Backup functions | Cloud, USB drive, iSCSI LUN |
| Audible alarm | Yes |
| Noise level | 19.6 dB |
| Third-party support | Yes |
| Image capture | Yes |
| Management protocols | SNMP |
| Web-based management | Yes |
| Managing access rights for the shared folder | Yes |
| Remote administration | 256-bit AES,FIPS 140-2,HTTPS,SNMP,SSH |
| Supported security algorithm | 256-bit AES, FIPS 140-2, HTTPS, SNMP, SSH |
| Access Control List (ACL) | Yes |
| Reset button | Yes |
| Integrated on/off button | Yes |
| Integrated BitTorrent client | Yes |
| Integrated FTP server | Yes |
| Supported browsers | Apple Safari 7+, Google Chrome, Microsoft Internet Explorer 10+, Mozilla Firefox |
| System journal | Yes |
| Hot exchange | Yes |
| SMART Support | Yes |
| Remote | Yes |
| Save button | Yes |
| Automatic recognition of computer components | Yes |
| USB copy function | Yes |
| Software | |
| Operating system installed | QNAP Turbo System |
| Operating system version | 5,0,0 |
| Windows operating system support | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64 |
| Linux operating system support | CentOS 7.0, Ubuntu 14.04 |
| Mac operating system support | Mac OS X 10.0 Cheetah, Mac OS |
| Server operating system support | Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Support for other operating systems | IBM AIX 7.1, IBM AIX 7.2, Solaris 10 |
| Power | |
| Power supply location | Integrated |
| Power supply unit (PSU) capacity | 250 W |
| Number of power supplies | 1 |
| Typical electricity consumption | 50,858 W |
| Energy consumption (in standby mode) | 27,949 W |
| AC input voltage | 100-240V |
| AC input frequency | 50-60 Hz |
| Fan voltage | 12V |
| Output current | 3.5 A |
| Weight and dimensions | |
| Width | 329.3 mm |
| Depth | 280.8 mm |
| Height | 188.2 mm |
| Weight | 6.38 kg |
| Package width | 8610 mm |
| Package contents | |
| Cables included | Sector, LAN (RJ-45) |
| Number of screws | 56 |
| Environmental conditions | |
| Operating temperature | 0 - 40 °C |
| Operating relative humidity (HH) | 5 - 95% |
| Off-temperature | -20 - 70 °C |
| Logistics data | |
| Harmonized System Code | 84714100 |
