Description
TP-Link Omada EAP670, 2.4 GHz, 5 GHz, 5400 Mbps, 2500 Mbps
| Features | |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| 6 GHz | No |
| Maximum data transfer rate | 5400 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 574 Mbit/s |
| Maximum data transfer rate (5 GHz) | 4804 Mbit/s |
| Ethernet LAN: data transfer rate | 2500 Mbit/s |
| Frequency band | 2.4 - 5 GHz |
| Network standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Number of users | 250 user(s) |
| Automatic channel selection | Yes |
| Automatic channel scanning | Yes |
| MIMO (multiple inputs, multiple outputs) | Yes |
| MIMO type | Multi-User MIMO |
| VLAN support | No |
| Flow rate limitation | Yes |
| Wireless isolation | Yes |
| Band direction | Yes |
| Quality of Service (QoS) | Yes |
| Beamforming | Yes |
| Transmission power (CE) | <20 dBm(2.4 GHz, EIRP); <23 dBm(5 GHz, band1 & band2, EIRP); <30 dBm (5 GHz, band3, EIRP) |
| Transmission power (FCC) | <25 dBm (2.4 GHz); <28 dBm (5 GHz) |
| Security | |
| Functions of the Service Set Identifier (SSID) | Multiple SSIDs |
| Number of SSID support | 16 |
| Remote Authentication Dial-In User Service (RADIUS) | Yes |
| Access Control List (ACL) | Yes |
| Management characteristics | |
| Web-based management | Yes |
| Upgradeable firmware | Yes |
| Power | |
| Ethernet connection, supporting power delivery via this port (PoE) | Yes |
| Input current | 1.5 A |
| Design | |
| Positioning | Ceiling, Wall |
| Product color | White |
| Code (IP) International Protection | IP67 |
| Reset button | Yes |
| Psychics | Yes |
| Antenna | |
| Antenna type | Internal |
| Antenna direction type | Omnidirectional |
| Antenna quantity | 6 |
| Antenna gain level (max) | 5 dBi |
| Certificate | |
| Certification | CE, FCC, RoHS |
| Weight and dimensions | |
| Width | 243 mm |
| Depth | 243 mm |
| Height | 64 mm |
| Packaging information | |
| Package width | 302 mm |
| Package depth | 304 mm |
| Package height | 82 mm |
| Package weight | 1.32 kg |
| Package contents | |
| Quantity | 1 piece(s) |
| Logistics data | |
| Harmonized System Code | 85176990 |
