Description
Powered by a quad-core Intel® Celeron® N5105/N5095 processor (capable of boosting to 2.9 GHz), the TS-464U-RP features two 2.5GbE RJ45 ports and port aggregation for a combined bandwidth of up to 5 Gbps. The integrated 4K HDMI output allows for displaying multimedia content and virtual machines. With a PCIe Gen 3 slot, the TS-464U-RP offers flexibility for expanding NAS functionality, allowing you to install various cards: a 10GbE/5GbE network card, a QM2 card for M.2 SSD caching, or an Edge TPU for AI image recognition. The TS-464U-RP also supports 256-bit AES encryption to ensure the confidentiality of sensitive business data without impacting system performance. The TS-464U-RP also features a redundant power supply ensuring that the system remains in operation for as long as possible.
High-performance quad-core processor with up to 16GB of RAM
The TS-464U-RP is powered by a quad-core Intel Celeron N5105/N5095 processor and supports up to 16GB of DDR4 memory, two 2.5GbE ports, and SATA 6Gb/s drives. The integrated Intel© AES-NI encryption engine also helps protect confidential data without impacting system performance.
Simplify large file transfers and video editing with 2.5GbE
The TS-464U-RP comes with two 2.5GbE (2.5G/1G/100M) RJ45 network ports, allowing you to use existing CAT5e cabling to upgrade network speeds from 1 to 2.5 Gigabit. These two 2.5GbE ports also support port aggregation for transfer speeds of up to 5 Gbps, improving the efficiency of bandwidth-intensive business applications such as large file transfers, fast backup/restore, and multimedia transfer and editing.
Future-proof your IT infrastructure for broadband networks
The TS-464U-RP is a perfect match for QNAP's managed and unmanaged 2.5GbE/10GbE switches, enabling you to build scalable, secure, and high-speed network environments without exceeding your budget. QNAP also provides 2.5GbE/5GbE/10GbE PCIe cards and 5GbE USB adapters for Windows©/Linux© workstations, allowing you to easily establish a high-speed network environment for productive team collaboration.
Boost your productivity with multiple USB ports
With two USB 3.2 Gen 2 (10 Gbps) ports and two USB 2.0 (480 Mbps) ports, you can quickly back up and transfer large files to and from the TS-464U-RP. UPS and other compatible USB devices can also be connected to expand functionality and application capabilities.
Large I/O capabilities with PCIe expansion
The TS-464U-RP has a PCIe Gen 3 x2 slot for installing expansion cards to increase application potential.
SSD caching and automatic tiering to optimize storage efficiency
The TS-464U-RP supports SSD caching to improve the workflow of demanding applications with high random IOPS, such as virtualization. Qtier™ technology equips the TS-464U-RP with automatic tiering that continuously optimizes storage utilization across high-performance SSDs and high-capacity SATA drives. Qtier™ 2.0 includes I/O awareness, which allows SSD storage to be prioritized with a reserved space acting as a cache to handle real-time burst I/O, greatly maximizing the benefits of SSDs.
Direct 4K HDMI output for displaying multimedia content and virtual machines
The TS-464U-RP features Intel® UHD Graphics, which supports dual-channel hardware decoding and real-time transcoding*. The HDMI 1.4b output supports up to 4K (3840 x 2160p) at 60 Hz, providing exceptional advantages for applications such as video production/editing or industrial design that require high resolution and color accuracy, as well as massive media storage, transfer, and display capabilities. By connecting the TS-464U-RP to an HDMI display, you can directly view media content stored on the NAS or use the TS-464U-RP as a versatile workstation by directly outputting virtual machines from Virtualization Station or Utilize Linux Station.
Faster image identification with the integrated Intel© OpenVINO™ AI engine.
Thanks to its integrated Intel© OpenVINO™ AI computing resources, the TS-464U-RP accelerates AI image recognition performance without impacting other applications or services. QNAP AI Core primarily works with the QuMagie application.
QTS 5, fast, smooth and easy to use!
The TS-464U-RP comes standard with the QTS 5 operating system, offering a next-generation user experience with an updated system kernel, an optimized user interface, and advanced security features.
Sharper. Smoother. You'll love it.
When you navigate QTS 5, you'll notice more attention to detail for a superior browsing experience. Enjoy a smoother NAS experience, a pleasing visual design, and faster access to your favorite apps.
Start with the scoreboard
During the initial setup, the display panel guides you through the configuration process. Simply follow the step-by-step instructions for a quick and easy setup.
Smooth and responsive user interface
Whether you're clicking buttons, switching apps, or resizing windows, every action is much smoother. The search bar in the main menu also helps you quickly find the apps you need.
Complete backup and disaster recovery solution
The TS-464U-RP supports various apps that cover all your backup needs. Develop secure computing habits by regularly backing up your files and device content, making it easy to restore them if necessary.
PC/Laptop Backup
For Windows©, install NetBak Replicator to back up your PC to your QNAP NAS. In macOS©, simply configure the built-in Time Machine© to secure your data.
Remote backup for the NAS
Hybrid Backup Sync makes it easy to back up data from a TS-464U-RP to another QNAP NAS or remote server to meet your 3-2-1 backup strategy.
VM backup
Take advantage of free backup of Vmware© and Hyper-V VMs with source-side incremental backup, global deduplication and restore compression.
SaaS Backup
Protect company cloud data by backing up/synchronizing files, emails, calendars and contacts from Google™ Workspace and Microsoft© Office 365© to the NAS.
Cloud backup for the NAS
Hybrid Backup Sync supports major cloud storage services for backing up NAS data. For backing up objects to cloud storage, VJBOD Cloud is particularly useful for reducing bandwidth usage and backup time.
QuDedup Technology
Hybrid Backup Sync eliminates redundant data at the source and then backs up the deduplicated data, saving time and storage costs while providing efficient multi-version backups.
Multi-version snapshots reduce ransomware threats
The TS-464U-RP supports block-based snapshots that record the system state at any given time. This helps protect data, which can be restored to a point in time, greatly reducing the threat of ransomware.
Snapshots of LUN and volume
Take snapshots in seconds and restore the entire volume/LUN to a specific point in time to prevent the loss of important data.
Restore snapshots instantly
The snapshot content can be quickly restored to a local NAS or restored based on a folder/file on a local or remote NAS, or to cloud storage. You can also easily view and restore snapshots on the client side.
Save the snapshots
Enhance your data protection by backing up snapshot files! Replicate volume/LUN snapshots from the TS-464U-RP to a remote NAS (Snapshot Replica) by copying only the changes made. This can save you time and bandwidth, and can be performed manually or on a schedule.
All-in-one solution for hosting virtual machines and containers
By running multiple virtual machines and containers on the TS-464U-RP, you can deploy multi-tenant environments and applications to increase management efficiency and save on hardware costs. Combined with the Network & Virtual Switch app, which enhances interoperability between virtual machines, containers, QNAP NAS, and other physical devices on the network, you can flexibly allocate physical and virtual network resources to simplify network deployment.
Virtualization Station
Run multiple Windows©, Linux©, UNIX©, Android™, and QuTScloud virtual machines and access them via a web browser or Virtual Network Computing (VNC). Businesses can run virtualized server applications on a single NAS without additional physical servers.
Container Station
Take advantage of the lightweight virtualization technologies of Docker©, LXD and Kata containers, download apps from the Docker Hub Registry©, import/export containers and create microservices in abundance.
Linux Station
Run Linux© applications (including apps from the Software Center) directly on the NAS and remotely access the Linux© desktop from a web browser. The open-source Linux© platform is also ideal for Internet of Things development.
Complete security and privilege settings
The TS-464U-RP features flexible privilege settings and security measures. In addition to IP blocking, two-step verification, and HTTPS connectivity, other applications help ensure optimal protection of the NAS against threats such as malware and hackers.
myQNAPcloud secures remote access
myQNAPcloud allows you to easily connect to the TS-464U-RP via the internet without complex DDNS settings. To ensure the security of your remote access service, myQNAPcloud strengthens the keys on the 2048-bit SSL certificates.
Simplified privilege settings
The TS-464U-RP supports comprehensive access rights settings for shared folders, Azure Active Directory Domain Services (Azure AD DS), LDAP, and Windows ACLs to help IT staff efficiently manage user accounts and access rights across multiple NAS systems.
Protection with QuFirewall
Supports IPv6, firewall access lists and GeoIP filtering to restrict access based on geographic location to enhance NAS network security.
Superior security with QVPN
A virtual private network (VPN) secures access to network resources and services over public networks. QVPN supports the creation of a VPN client, using the TS-464U-RP as a VPN server and the WireGuard© VPN service with a user-friendly interface for setting up a secure connection.
SD-WAN QuWAN
To facilitate digital transformation, multi-site expansion, and remote work, QuWAN SD-WAN helps automatically mesh multi-site VPNs. It includes IPsec encryption and cloud-based management, enabling the security of multi-site networks, including QNAP NAS and VMware ESXi platforms.
Security Counselor
A security portal allows the TS-464U-RP to scan for vulnerabilities and provide recommendations for improving NAS security. It also includes antivirus and anti-malware scanning software.
The best file storage and collaboration center
The TS-464U-RP integrates a wealth of applications for storing, managing, synchronizing, searching, and archiving files. It supports SMB/CIFS, AFP, and NFS protocols to simplify file sharing across Windows©, Mac©, and Linux©/UNIX©. Furthermore, it offers the most intelligent NAS solution for managing your files professionally.
File Station
Manage, access, and share all files on the TS-464U-RP and view snapshot files—all from your web browser. You can also easily mount remote NAS folders and cloud storage.
Qsync
Make any file transferred to a TS-464U-RP available to connected devices, such as computers, laptops, and mobile devices. You can synchronize shared folders and team folders for group file sharing to improve the flexibility of team projects and collaborative work.
Qsirch
QNAP's powerful search tool, similar to Google, helps you quickly find specific images, music, videos, documents, and emails by keywords, color, and more search criteria. It also supports Qfiling to perform one-time or automatic archiving tasks based on your search criteria.
Qfiling
Automate your file organization – simply define file categories and set up a schedule. Qfiling takes care of the rest. Qfiling also offers intelligent recycling that instantly moves filtered files to the Recycle Bin.
High-performance quad-core processor with up to 16GB of RAM
The TS-464U-RP is powered by a quad-core Intel Celeron N5105/N5095 processor and supports up to 16GB of DDR4 memory, two 2.5GbE ports, and SATA 6Gb/s drives. The integrated Intel© AES-NI encryption engine also helps protect confidential data without impacting system performance.
Simplify large file transfers and video editing with 2.5GbE
The TS-464U-RP comes with two 2.5GbE (2.5G/1G/100M) RJ45 network ports, allowing you to use existing CAT5e cabling to upgrade network speeds from 1 to 2.5 Gigabit. These two 2.5GbE ports also support port aggregation for transfer speeds of up to 5 Gbps, improving the efficiency of bandwidth-intensive business applications such as large file transfers, fast backup/restore, and multimedia transfer and editing.
Future-proof your IT infrastructure for broadband networks
The TS-464U-RP is a perfect match for QNAP's managed and unmanaged 2.5GbE/10GbE switches, enabling you to build scalable, secure, and high-speed network environments without exceeding your budget. QNAP also provides 2.5GbE/5GbE/10GbE PCIe cards and 5GbE USB adapters for Windows©/Linux© workstations, allowing you to easily establish a high-speed network environment for productive team collaboration.
Boost your productivity with multiple USB ports
With two USB 3.2 Gen 2 (10 Gbps) ports and two USB 2.0 (480 Mbps) ports, you can quickly back up and transfer large files to and from the TS-464U-RP. UPS and other compatible USB devices can also be connected to expand functionality and application capabilities.
Large I/O capabilities with PCIe expansion
The TS-464U-RP has a PCIe Gen 3 x2 slot for installing expansion cards to increase application potential.
SSD caching and automatic tiering to optimize storage efficiency
The TS-464U-RP supports SSD caching to improve the workflow of demanding applications with high random IOPS, such as virtualization. Qtier™ technology equips the TS-464U-RP with automatic tiering that continuously optimizes storage utilization across high-performance SSDs and high-capacity SATA drives. Qtier™ 2.0 includes I/O awareness, which allows SSD storage to be prioritized with a reserved space acting as a cache to handle real-time burst I/O, greatly maximizing the benefits of SSDs.
Direct 4K HDMI output for displaying multimedia content and virtual machines
The TS-464U-RP features Intel® UHD Graphics, which supports dual-channel hardware decoding and real-time transcoding*. The HDMI 1.4b output supports up to 4K (3840 x 2160p) at 60 Hz, providing exceptional advantages for applications such as video production/editing or industrial design that require high resolution and color accuracy, as well as massive media storage, transfer, and display capabilities. By connecting the TS-464U-RP to an HDMI display, you can directly view media content stored on the NAS or use the TS-464U-RP as a versatile workstation by directly outputting virtual machines from Virtualization Station or Utilize Linux Station.
Faster image identification with the integrated Intel© OpenVINO™ AI engine.
Thanks to its integrated Intel© OpenVINO™ AI computing resources, the TS-464U-RP accelerates AI image recognition performance without impacting other applications or services. QNAP AI Core primarily works with the QuMagie application.
QTS 5, fast, smooth and easy to use!
The TS-464U-RP comes standard with the QTS 5 operating system, offering a next-generation user experience with an updated system kernel, an optimized user interface, and advanced security features.
Sharper. Smoother. You'll love it.
When you navigate QTS 5, you'll notice more attention to detail for a superior browsing experience. Enjoy a smoother NAS experience, a pleasing visual design, and faster access to your favorite apps.
Start with the scoreboard
During the initial setup, the display panel guides you through the configuration process. Simply follow the step-by-step instructions for a quick and easy setup.
Smooth and responsive user interface
Whether you're clicking buttons, switching apps, or resizing windows, every action is much smoother. The search bar in the main menu also helps you quickly find the apps you need.
Complete backup and disaster recovery solution
The TS-464U-RP supports various apps that cover all your backup needs. Develop secure computing habits by regularly backing up your files and device content, making it easy to restore them if necessary.
PC/Laptop Backup
For Windows©, install NetBak Replicator to back up your PC to your QNAP NAS. In macOS©, simply configure the built-in Time Machine© to secure your data.
Remote backup for the NAS
Hybrid Backup Sync makes it easy to back up data from a TS-464U-RP to another QNAP NAS or remote server to meet your 3-2-1 backup strategy.
VM backup
Take advantage of free backup of Vmware© and Hyper-V VMs with source-side incremental backup, global deduplication and restore compression.
SaaS Backup
Protect company cloud data by backing up/synchronizing files, emails, calendars and contacts from Google™ Workspace and Microsoft© Office 365© to the NAS.
Cloud backup for the NAS
Hybrid Backup Sync supports major cloud storage services for backing up NAS data. For backing up objects to cloud storage, VJBOD Cloud is particularly useful for reducing bandwidth usage and backup time.
QuDedup Technology
Hybrid Backup Sync eliminates redundant data at the source and then backs up the deduplicated data, saving time and storage costs while providing efficient multi-version backups.
Multi-version snapshots reduce ransomware threats
The TS-464U-RP supports block-based snapshots that record the system state at any given time. This helps protect data, which can be restored to a point in time, greatly reducing the threat of ransomware.
Snapshots of LUN and volume
Take snapshots in seconds and restore the entire volume/LUN to a specific point in time to prevent the loss of important data.
Restore snapshots instantly
The snapshot content can be quickly restored to a local NAS or restored based on a folder/file on a local or remote NAS, or to cloud storage. You can also easily view and restore snapshots on the client side.
Save the snapshots
Enhance your data protection by backing up snapshot files! Replicate volume/LUN snapshots from the TS-464U-RP to a remote NAS (Snapshot Replica) by copying only the changes made. This can save you time and bandwidth, and can be performed manually or on a schedule.
All-in-one solution for hosting virtual machines and containers
By running multiple virtual machines and containers on the TS-464U-RP, you can deploy multi-tenant environments and applications to increase management efficiency and save on hardware costs. Combined with the Network & Virtual Switch app, which enhances interoperability between virtual machines, containers, QNAP NAS, and other physical devices on the network, you can flexibly allocate physical and virtual network resources to simplify network deployment.
Virtualization Station
Run multiple Windows©, Linux©, UNIX©, Android™, and QuTScloud virtual machines and access them via a web browser or Virtual Network Computing (VNC). Businesses can run virtualized server applications on a single NAS without additional physical servers.
Container Station
Take advantage of the lightweight virtualization technologies of Docker©, LXD and Kata containers, download apps from the Docker Hub Registry©, import/export containers and create microservices in abundance.
Linux Station
Run Linux© applications (including apps from the Software Center) directly on the NAS and remotely access the Linux© desktop from a web browser. The open-source Linux© platform is also ideal for Internet of Things development.
Complete security and privilege settings
The TS-464U-RP features flexible privilege settings and security measures. In addition to IP blocking, two-step verification, and HTTPS connectivity, other applications help ensure optimal protection of the NAS against threats such as malware and hackers.
myQNAPcloud secures remote access
myQNAPcloud allows you to easily connect to the TS-464U-RP via the internet without complex DDNS settings. To ensure the security of your remote access service, myQNAPcloud strengthens the keys on the 2048-bit SSL certificates.
Simplified privilege settings
The TS-464U-RP supports comprehensive access rights settings for shared folders, Azure Active Directory Domain Services (Azure AD DS), LDAP, and Windows ACLs to help IT staff efficiently manage user accounts and access rights across multiple NAS systems.
Protection with QuFirewall
Supports IPv6, firewall access lists and GeoIP filtering to restrict access based on geographic location to enhance NAS network security.
Superior security with QVPN
A virtual private network (VPN) secures access to network resources and services over public networks. QVPN supports the creation of a VPN client, using the TS-464U-RP as a VPN server and the WireGuard© VPN service with a user-friendly interface for setting up a secure connection.
SD-WAN QuWAN
To facilitate digital transformation, multi-site expansion, and remote work, QuWAN SD-WAN helps automatically mesh multi-site VPNs. It includes IPsec encryption and cloud-based management, enabling the security of multi-site networks, including QNAP NAS and VMware ESXi platforms.
Security Counselor
A security portal allows the TS-464U-RP to scan for vulnerabilities and provide recommendations for improving NAS security. It also includes antivirus and anti-malware scanning software.
The best file storage and collaboration center
The TS-464U-RP integrates a wealth of applications for storing, managing, synchronizing, searching, and archiving files. It supports SMB/CIFS, AFP, and NFS protocols to simplify file sharing across Windows©, Mac©, and Linux©/UNIX©. Furthermore, it offers the most intelligent NAS solution for managing your files professionally.
File Station
Manage, access, and share all files on the TS-464U-RP and view snapshot files—all from your web browser. You can also easily mount remote NAS folders and cloud storage.
Qsync
Make any file transferred to a TS-464U-RP available to connected devices, such as computers, laptops, and mobile devices. You can synchronize shared folders and team folders for group file sharing to improve the flexibility of team projects and collaborative work.
Qsirch
QNAP's powerful search tool, similar to Google, helps you quickly find specific images, music, videos, documents, and emails by keywords, color, and more search criteria. It also supports Qfiling to perform one-time or automatic archiving tasks based on your search criteria.
Qfiling
Automate your file organization – simply define file categories and set up a schedule. Qfiling takes care of the rest. Qfiling also offers intelligent recycling that instantly moves filtered files to the Recycle Bin.
| storage media | |
| Installed storage drives | No |
| Total installed storage capacity | 0 TB |
| Number of storage drives installed | 0 |
| Number of storage units supported | 4 |
| Type of storage drive installed | No |
| Supported storage drive types | HDD & SSD |
| RAID support | Yes |
| Supported storage drive interfaces | ATA Series II, ATA Series III |
| Supported storage disk sizes | 2.5, 3.5" |
| RAID Levels | 0, 6, 1, JBOD, 5, 10 |
| Online RAID Migration | Yes |
| Online RAID expansion | Yes |
| RAID Reconstruction | Yes |
| Hot-swappable enclosure bays | Yes |
| Supported file systems | FAT32, exFAT, HFS+, NTFS, ext3, ext4 |
| Disk roaming | Yes |
| Processor | |
| Processor family | Intel® Celeron® |
| Processor manufacturer | Intel |
| Processor model | N5095 |
| Processor frequency | 2 GHz |
| Turbo processor frequency | 2.9 GHz |
| Number of processor cores | 4 |
| Number of processor threads | 4 |
| CPU configuration (max) | 1 |
| Graphics adapter model included | Intel® UHD Graphics |
| Memory | |
| Internal memory | 8 GB |
| Internal memory type | DDR4 |
| Maximum RAM supported | 16 GB |
| Memory locations | 2 |
| Memory support | SO-DIMM |
| Flash memory | 4000 MB |
| Network | |
| Ethernet/LAN | Yes |
| Ethernet LAN: data transfer rate | 10, 1000, 2500, 100 Mbit/s |
| Copper Ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T, 2500BASE-T |
| DHCP Server | Yes |
| Support for Jumbo Frames | Yes |
| iSCSI support | Yes |
| Wake-on-LAN ready | Yes |
| Dynamic DNS (DDNS) | Yes |
| Connectivity | |
| Number of LAN ethernet ports (RJ-45) | 2 |
| USB port | Yes |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports | 0 |
| Number of USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports | 2 |
| Number of HDMI ports | 1 |
| HDMI version | 1.4b |
| Simultaneous connections | 1500 |
| PCI Express x2 slots (Gen. 3.x) | 1 |
| Design | |
| Chassis type | Rack (1U) |
| Cooling type | Active |
| Product color | Aluminum, Black |
| Number of fans | 2 fan(s) |
| Fan diameter | 4 cm |
| Psychics | HDD, Status, Power, LAN |
| representation / realization | |
| Kind | NAS |
| Device class | SMEs |
| Backup function | Yes |
| Backup functions | Cloud, iSCSI LUN |
| Audible alarm | Yes |
| Multilingual support | Yes |
| Image capture | Yes |
| Management protocols | SNMP V2, V3 |
| Supported security algorithm | 256-bit AES, FIPS 140-2, HTTPS, SNMPv2, SNMPv3, SSH |
| Access Control List (ACL) | Yes |
| Reset button | Yes |
| Integrated on/off button | Yes |
| Integrated FTP server | Yes |
| Supported browsers | Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox |
| System journal | Yes |
| Hot exchange | Yes |
| Disk analysis | Yes |
| SMART Support | Yes |
| Shared folder | CIFS/SMB |
| Software | |
| Operating system installed | QNAP Turbo System |
| Operating system version | 5,0,1 |
| Windows operating system support | Windows 10, Windows 8, Windows 7, Windows 11 |
| Linux operating system support | Ubuntu 14.04 |
| Mac operating system support | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS 13.0 Ventura |
| Server operating system support | Windows Server 2019, Windows Server 2012 R2, Windows Server 2008 R2, Windows Server 2016, Windows Server 2012 |
| Support for other operating systems | Solaris 10 |
| Power | |
| Power supply location | Integrated |
| Power supply unit (PSU) capacity | 250 W |
| Number of power supplies | 2 |
| Redundant Power Supply (RPS) | Yes |
| Typical electricity consumption | 51,404 W |
| Energy consumption (in standby mode) | 37,469 W |
| AC input voltage | 100-240V |
| Fan voltage | 12V |
| Weight and dimensions | |
| Width | 430 mm |
| Depth | 479 mm |
| Height | 43.3 mm |
| Weight | 8.12 kg |
| Package weight | 10.1 kg |
| Package contents | |
| Cables included | Sector, LAN (RJ-45) |
| Quantity of power cables | 2 |
| Number of screws | 84 |
| Special features of the processor | |
| Intel's Advanced SpeedStep Technology | Yes |
| Idle States | Yes |
| Intel® 64 | Yes |
| Intel® Trusted Execution Technology | No |
| Intel® Vitalization Technology (VT-x) | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® VT-x with Extended Page Tables (EPT) | Yes |
| Environmental conditions | |
| Operating temperature | 0 - 40 °C |
| Operating relative humidity (HH) | 5 - 95% |
| Off-temperature | -20 - 70 °C |
| Relative humidity level (storage) | 5 - 95% |
| Logistics data | |
| Harmonized System Code | 84714100 |
