Description
TS-432PXU
1.7 GHz quad-core rack-mountable NAS with two 10GbE SFP+ ports and two 2.5GbE ports for SMB IT environments
With its 10GbE SFP+ and 2.5GbE network ports, the TS-432PXU delivers high network bandwidth for seamless team collaboration and file access. A PCIe Gen 2 x2 slot allows for the installation of a QNAP expansion card to add network connectivity, SSD caching capabilities, or wireless connectivity. The TS-432PXU supports backup and synchronization, secure snapshot protection, and backup services for Google™ Workspace and Microsoft 365© business accounts, while also providing instant restore when needed. Combined with cloud gateway support, setting up a hybrid cloud storage solution has never been easier.
Superior performance x faster throughput
The TS-432PXU is powered by a quad-core Annapurna Labs Alpine AL-324 ARM© Cortex©-A57 1.7 GHz processor with 2 GB of DDR4 RAM (expandable up to 16 GB) and SATA 6 Gb/s drives to deliver superior performance. With two 10GbE SFP+ network ports and two 2.5GbE ports, the TS-432PXU provides incredible bandwidth for high-speed file access, backup/restore, and multimedia transfer. It also allows for flexible allocation of network resources for individual applications and services.
Upgrade your network to increase team efficiency
QNAP offers a variety of high-speed networking solutions at affordable prices. QSW network switches provide 10GbE and 2.5GbE managed and unmanaged options for building high-speed networks. QNAP also offers 10GbE/5GbE/2.5GbE network expansion cards and a USB-to-5GbE adapter for Windows©/Linux© devices. This allows all your workstations to benefit from high-speed networks.
Boost NAS performance with SSDs
With SSDs becoming more affordable, their use in NAS devices can improve performance without requiring a large investment. The TS-432PXU supports SSD caching technology, Qtier™ auto-tiering storage, and SSD over-provisioning, helping you balance storage performance, storage allocation, and IT spending.
Balance performance and capabilities
Boost NAS performance by enabling SSD caching. Combined with Qtier™ auto-tiering technology, you can find the perfect storage configuration between high-performance SSDs and high-capacity hard drives while balancing performance and cost.
Increase the lifespan of SSDs
SSD over-provisioning allows you to add 1 to 60% more reserved space to avoid performance degradation, which helps increase system stability and extend the lifespan of SSDs.
Backup, access and synchronization of files Multipoint
HBS (Hybrid Backup Sync) consolidates data backup, restore, and synchronization. With high-speed 10GbE connectivity, you can easily back up or synchronize data to another QNAP NAS, remote server, or cloud storage to establish a reliable disaster recovery solution. Qsync transforms the TS-432PXU into a secure, high-capacity data center for file synchronization. Any file transferred to the TS-432PXU will be made available on all linked devices, such as desktops, laptops, and mobile devices. You can also synchronize shared folders or create team folders to improve team collaboration.
Easily find and automatically organize files and photos
The TS-432PXU offers superior file management convenience. You can quickly find files using Qsirch, organize photos with QuMagie, and automatically archive them with Qfiling.
File search
Qsirch quickly finds images, music, videos, documents, emails and other files using keywords, colors and various filters.
Photo management
QuMagie identifies people and objects in photos and supports automated photo sorting, allowing you to easily find similar photos.
Automatic archiving
Qfiling automates the organization or recycling of files based on self-configured rules, which greatly improves work efficiency.
Secure your Google™ Workspace and Microsoft 365© backups
The advantages of Software as a Service (SaaS) solutions such as Google Workspace and Microsoft 365 have led to their adoption by numerous businesses and organizations. However, many users struggle to protect this cloud data against data loss, data recovery limitations, and human error. The TS-432PXU includes QNAP Boxafe, enabling you to back up files, emails, calendars, and contacts from Google Workspace and Microsoft 365, providing an additional layer of data protection for your business cloud data.
Access to low-latency cloud data via cloud storage gateways
By deploying cloud storage gateways and enabling local caching on the TS-432PXU, you can perfectly utilize the cloud for data storage, backup, and restoration with low-latency access, thus providing an innovative hybrid cloud experience.
HybridMount file-based cloud gateway
Flexibly expand your storage capacity by connecting to cloud storage. You can leverage QTS apps to manage and edit your cloud files or monitor multimedia files. HybridMount is ideal for online collaboration across file servers and for file-level data analysis.
VJBOD Cloud Block-Based Cloud Gateway
VJBOD Cloud supports backing up data from your NAS to block-based cloud storage. Block-based data transmission transfers random data and large files to the cloud in blocks. Furthermore, it transmits only block-based volume or LUN changes. This is ideal for backing up LUNs, databases, and sensitive files.
Flexible expansion of storage capacity, if needed
You can easily expand the storage capacity of the TS-432PXU to meet growing data demands. Simply connect a QNAP TR RAID expansion enclosure or a TL JBOD to increase storage space on demand. Thanks to QNAP's Virtual JBOD (VJBOD) technology, unused space on the TS-432PXU can also be used to expand the storage capacity of another QNAP NAS.
1.7 GHz quad-core rack-mountable NAS with two 10GbE SFP+ ports and two 2.5GbE ports for SMB IT environments
With its 10GbE SFP+ and 2.5GbE network ports, the TS-432PXU delivers high network bandwidth for seamless team collaboration and file access. A PCIe Gen 2 x2 slot allows for the installation of a QNAP expansion card to add network connectivity, SSD caching capabilities, or wireless connectivity. The TS-432PXU supports backup and synchronization, secure snapshot protection, and backup services for Google™ Workspace and Microsoft 365© business accounts, while also providing instant restore when needed. Combined with cloud gateway support, setting up a hybrid cloud storage solution has never been easier.
Superior performance x faster throughput
The TS-432PXU is powered by a quad-core Annapurna Labs Alpine AL-324 ARM© Cortex©-A57 1.7 GHz processor with 2 GB of DDR4 RAM (expandable up to 16 GB) and SATA 6 Gb/s drives to deliver superior performance. With two 10GbE SFP+ network ports and two 2.5GbE ports, the TS-432PXU provides incredible bandwidth for high-speed file access, backup/restore, and multimedia transfer. It also allows for flexible allocation of network resources for individual applications and services.
Upgrade your network to increase team efficiency
QNAP offers a variety of high-speed networking solutions at affordable prices. QSW network switches provide 10GbE and 2.5GbE managed and unmanaged options for building high-speed networks. QNAP also offers 10GbE/5GbE/2.5GbE network expansion cards and a USB-to-5GbE adapter for Windows©/Linux© devices. This allows all your workstations to benefit from high-speed networks.
Boost NAS performance with SSDs
With SSDs becoming more affordable, their use in NAS devices can improve performance without requiring a large investment. The TS-432PXU supports SSD caching technology, Qtier™ auto-tiering storage, and SSD over-provisioning, helping you balance storage performance, storage allocation, and IT spending.
Balance performance and capabilities
Boost NAS performance by enabling SSD caching. Combined with Qtier™ auto-tiering technology, you can find the perfect storage configuration between high-performance SSDs and high-capacity hard drives while balancing performance and cost.
Increase the lifespan of SSDs
SSD over-provisioning allows you to add 1 to 60% more reserved space to avoid performance degradation, which helps increase system stability and extend the lifespan of SSDs.
Backup, access and synchronization of files Multipoint
HBS (Hybrid Backup Sync) consolidates data backup, restore, and synchronization. With high-speed 10GbE connectivity, you can easily back up or synchronize data to another QNAP NAS, remote server, or cloud storage to establish a reliable disaster recovery solution. Qsync transforms the TS-432PXU into a secure, high-capacity data center for file synchronization. Any file transferred to the TS-432PXU will be made available on all linked devices, such as desktops, laptops, and mobile devices. You can also synchronize shared folders or create team folders to improve team collaboration.
Easily find and automatically organize files and photos
The TS-432PXU offers superior file management convenience. You can quickly find files using Qsirch, organize photos with QuMagie, and automatically archive them with Qfiling.
File search
Qsirch quickly finds images, music, videos, documents, emails and other files using keywords, colors and various filters.
Photo management
QuMagie identifies people and objects in photos and supports automated photo sorting, allowing you to easily find similar photos.
Automatic archiving
Qfiling automates the organization or recycling of files based on self-configured rules, which greatly improves work efficiency.
Secure your Google™ Workspace and Microsoft 365© backups
The advantages of Software as a Service (SaaS) solutions such as Google Workspace and Microsoft 365 have led to their adoption by numerous businesses and organizations. However, many users struggle to protect this cloud data against data loss, data recovery limitations, and human error. The TS-432PXU includes QNAP Boxafe, enabling you to back up files, emails, calendars, and contacts from Google Workspace and Microsoft 365, providing an additional layer of data protection for your business cloud data.
Access to low-latency cloud data via cloud storage gateways
By deploying cloud storage gateways and enabling local caching on the TS-432PXU, you can perfectly utilize the cloud for data storage, backup, and restoration with low-latency access, thus providing an innovative hybrid cloud experience.
HybridMount file-based cloud gateway
Flexibly expand your storage capacity by connecting to cloud storage. You can leverage QTS apps to manage and edit your cloud files or monitor multimedia files. HybridMount is ideal for online collaboration across file servers and for file-level data analysis.
VJBOD Cloud Block-Based Cloud Gateway
VJBOD Cloud supports backing up data from your NAS to block-based cloud storage. Block-based data transmission transfers random data and large files to the cloud in blocks. Furthermore, it transmits only block-based volume or LUN changes. This is ideal for backing up LUNs, databases, and sensitive files.
Flexible expansion of storage capacity, if needed
You can easily expand the storage capacity of the TS-432PXU to meet growing data demands. Simply connect a QNAP TR RAID expansion enclosure or a TL JBOD to increase storage space on demand. Thanks to QNAP's Virtual JBOD (VJBOD) technology, unused space on the TS-432PXU can also be used to expand the storage capacity of another QNAP NAS.
| Storage media | |
| Installed storage drives | No |
| Total installed storage capacity | 0 TB |
| Number of storage drives installed | 0 |
| Number of storage units supported | 4 |
| Type of storage drive installed | No |
| Supported storage drive types | HDD & SSD |
| Storage drive capacity | 0 GB |
| RAID support | Yes |
| Supported storage drive interfaces | ATA Series II, ATA Series III |
| Supported storage disk sizes | 2.5, 3.5" |
| RAID Levels | 0, 1, 5, 6, 10, JBOD |
| Online RAID Migration | Yes |
| Online RAID expansion | Yes |
| RAID Reconstruction | Yes |
| Hot-swappable enclosure bays | Yes |
| Supported file systems | FAT32, HFS+, NTFS, ext3, ext4 |
| Faulty block scan | Yes |
| Processor | |
| Processor family | Annapurna Labs |
| Processor manufacturer | Annapurna Labs |
| Processor model | Alpine AL-324 |
| Processor frequency | 1.7 GHz |
| Number of processor cores | 4 |
| Memory | |
| Internal memory | 2 GB |
| Internal memory type | DDR4 |
| Maximum RAM supported | 16 GB |
| Memory locations | 1 |
| Memory support | UDIMM |
| Flash memory | 512 MB |
| Network | |
| Ethernet/LAN | Yes |
| Ethernet LAN: data transfer rate | 100, 1000, 2500, 10000 Mbit/s |
| Supported Ethernet LAN transmission speed (max.) | 10000 Mbit/s |
| DHCP Client | Yes |
| DHCP Server | Yes |
| Support for Jumbo Frames | Yes |
| iSCSI support | Yes |
| Wake-on-LAN ready | Yes |
| Supported network protocols | PPTP, L2TP/IPSec, OpenVPN, QBelt |
| Link aggregation | Yes |
| Load balancing system | Yes |
| WLAN adapter supported | Yes |
| Connectivity | |
| Number of LAN ethernet ports (RJ-45) | 2 |
| USB port | Yes |
| Number of USB 2.0 Ports | 0 |
| Number of USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports | 4 |
| Fibre Channel Ports | 2 |
| Fiber optic connector | SFP+ |
| Design | |
| Chassis type | Rack (1U) |
| Cooling type | Active |
| Product color | Black |
| Number of fans | 2 fan(s) |
| Fan diameter | 4 cm |
| Psychics | HDD, LAN, Status |
| representation / realization | |
| Kind | NAS |
| Device class | SMEs |
| Backup function | Yes |
| Backup functions | Cloud, iSCSI LUN |
| Audible alarm | Yes |
| Multilingual support | Yes |
| Noise level | 38 dB |
| Image capture | Yes |
| Web-based management | Yes |
| Supported security algorithm | 256-bit AES, FIPS 140-2, HTTPS, SSH, SSL/TLS |
| Access Control List (ACL) | Yes |
| Reset button | Yes |
| Integrated on/off button | Yes |
| Integrated FTP server | Yes |
| Supported browsers | Mozilla Firefox, Microsoft Internet Explorer 10+, Apple Safari 7+, Google Chrome |
| System journal | Yes |
| Hot exchange | Yes |
| SMART Support | Yes |
| Shared folder | CIFS/SMB |
| Automatic recognition of computer components | Yes |
| USB copy function | Yes |
| Software | |
| Operating system installed | QNAP Turbo System |
| Operating system version | 5,0,0 |
| Windows operating system support | Windows 10, Windows 7, Windows 8 |
| Linux operating system support | Yes |
| Mac operating system support | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS |
| Server operating system support | Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Power | |
| Power supply location | Integrated |
| Power supply unit (PSU) capacity | 250 W |
| Number of power supplies | 1 |
| Typical electricity consumption | 39,558 W |
| AC input voltage | 100-240V |
| Fan voltage | 12V |
| Weight and dimensions | |
| Width | 439 mm |
| Depth | 499 mm |
| Height | 44 mm |
| Weight | 6.53 kg |
| Package weight | 9.53 kg |
| Package contents | |
| Cables included | Sector, LAN (RJ-45) |
| Number of screws | 28 |
| Environmental conditions | |
| Operating temperature | 0 - 40 °C |
| Operating relative humidity (HH) | 5 - 95% |
| Logistics data | |
| Harmonized System Code | 84714100 |
