Description
TS-1673AU-RP
High-performance dual 2.5GbE NAS powered by a quad-core AMD Ryzen™ processor, supporting PCIe 10GbE expandability or M.2 SSD cache for virtual applications
(Supports the QTS or QuTS hero system)
Thanks to its powerful quad-core AMD Ryzen™ V1500B processor from the V1000 series, the TS-1673AU-RP can boost virtual machine performance with up to 4 cores/8 threads at 2.2 GHz. The TS-1673AU-RP includes two 2.5GbE ports and two PCIe Gen 3 slots, providing fast network connectivity and the ability to add features and expand application capabilities. The TS-1673AU-RP also features a redundant power supply, ensuring maximum system uptime. The advanced hardware combined with comprehensive software solutions makes the TS-1673AU-RP the preferred choice for resource-intensive applications and tasks. The TS-1673AU-RP supports QTS and QuTS hero, allowing users to flexibly switch operating systems as needed.
Absolute performance with AMD Ryzen™ and up to 64GB of RAM
Powered by a quad-core AMD Ryzen™ V1500B 2.2GHz processor with AES-NI encryption acceleration and up to 64GB of DDR4 RAM, the rack-mounted TS-1673AU-RP delivers smart yet aggressive performance to run resource-intensive business applications such as VDI, R&D, private cloud, and server virtualization.
Block-based iSCSI LUN: The ideal choice for virtualization storage
The TS-1673AU-RP supports block-based iSCSI LUNs and is compatible with VMware©, Citrix©, Microsoft© Hyper-V©, and Windows Server© 2019 virtualization environments, providing an affordable, high-performance storage solution. The TS-1673AU-RP also supports VMware VAAI and Microsoft ODX to boost performance by offloading tasks from the ESXi and Hyper-V servers, respectively. The QNAP vSphere Client plug-in is also supported, improving operational efficiency and management in virtualization applications.
Optimized performance for VMware virtualization thanks to iSER
The iSER (iSCSI Extensions for RDMA) protocol boosts data transfer performance for VMware© ESXi storage and reduces the CPU load on the ESXi server. iSER support can be added to the TS-1673AU-RP by installing a QNAP QXG-10G2SF-CX4 10GbE PCIe card that uses the NVIDIA© Mellanox ConnectX-4 controller. iSER can provide a significant performance increase, offering an essential tool for optimizing demanding virtualization applications.
All-in-one server for hosting virtual machines and containers
Whatever your virtualization needs, you can rely on Virtualization Station and Container Station for comprehensive virtualization support. Use the Network & Virtual Switch app to allocate the appropriate physical network resources to virtual machines, containers, and the TS-1673AU-RP to simplify network deployment.
Upgrade to a 2.5GbE network
The TS-1673AU-RP comes with two 2.5GbE RJ45 network ports, allowing you to use existing CAT5e cables to upgrade network speeds from 1 to 2.5 Gigabit. You can also achieve 5GbE speeds using Port Aggregation. To upgrade your laptops and desktops to take advantage of high-speed networks, QNAP offers various adapters and peripherals, including a USB 3.2 Gen 1 to 5GbE adapter (model name QNA-UC5G1T) and a 5GbE PCIe expansion card (model name QXG-5G1T-111C).
Transform your network with an affordable 2.5GbE switch
You shouldn't break the bank to upgrade your network, and 2.5GbE connectivity immediately provides noticeable improvements over standard 1GbE. The QSW-1105-5T is an unmanaged switch with five 2.5GbE ports (backward compatible with 1GbE/100M) that supports CAT5e cables for connecting multiple computers and NAS devices. The QSW-1105-5T is energy-efficient, quiet, plug-and-play, and supports loop detection and blocking to provide a simple and effective high-speed network environment.
Large I/O capacities with PCIe expansion
The TS-1673AU-RP features two PCIe Gen 3 x4 slots, allowing you to add functionality with compatible PCIe cards. Using a suitable adapter, you can consolidate the two slots into a single PCIe Gen 3 x8 slot.
GPU-accelerated computing
Graphics cards are optimized for graphics processing and calculations but require significantly more power than other hardware. The TS-1673AU-RP supports low-profile, entry-level NVIDIA© GeForce© graphics cards (such as the GT 1030 or GT 1050) that do not require additional power. Installing a graphics card can boost the performance of applications such as video editing, 4K video transcoding, image processing in QTS, and virtual machine performance via GPU passthrough.
Accelerate IOPS performance with SSD caching
Adding an SSD cache to the TS-1673AU-RP is a simple way to improve IOPS performance and reduce storage volume latency. It's ideal for IOPS-intensive applications (especially databases and virtualization) and can significantly improve overall workflows. You can start, stop, or modify settings at any time to suit your needs without shutting down the system.
Migrate business data to the cloud smoothly and at a lower cost
By deploying cloud storage gateways and enabling local caching on the TS-1673AU-RP, you can perfectly utilize the cloud for data storage, backup, and restoration with low-latency access, thus providing an innovative hybrid cloud experience.
Full backup planning
The TS-1673AU-RP offers reliable and cost-effective solutions for backup planning and disaster recovery.
HBS
It brings together backup, restore and synchronization functions (using RTRR, Rsync, FTP, CIFS/SMB), in order to easily transfer data to local, remote or cloud storage spaces, such as a complete data storage or disaster recovery plan.
Snapshots for Volume and LUN
Snapshots are essential for protecting NAS data, and their block-level functionality makes them a reliable method for safeguarding against the growing threat of ransomware. The TS-1673AU-RP supports up to 256 snapshots per volume/LUN, and up to 1,024 snapshots per NAS.
VM backup
Thanks to high performance, huge storage potential, built-in virtualization solutions, and support for snapshots that record the system state at any time, the TS-1673AU-RP is perfect for backing up virtual machines.
Windows© and Mac© Backup
Use the license-free QNAP NetBak Replicator utility to back up and restore files from Windows© computers. Time Machine© is also supported for backing up Mac© computers.
High-speed VM backup solution
Thanks to Hyper Data Protector, the TS-1673AU-RP becomes an agentless backup tool for unlimited VMware© vSphere and Microsoft© Hyper-V VM backups. Hyper Data Protector includes incremental backup, global deduplication, backup scheduling, and restore compression, providing you with a cost-effective and reliable disaster recovery plan. This ensures your services operate 24/7.
Build an affordable Fibre Channel SAN environment
Typical Fibre Channel Storage Area Network (SAN) devices are often expensive. By installing a QNAP 16 Gbps Fibre Channel card (QXP-16G2FC 16Gb) in the TS-1673AU-RP, you can configure a Fibre Channel Target using the iSCSI & Fibre Channel app. Additionally, LUN masking and port binding features provide an extra layer of data security.
Flexible and economical storage expansion
QNAP provides simple storage expansion solutions. Here are several ways to increase the storage capacity of your TS-1673AU-RP to accommodate your growing data and business.
Add expansion boxes
In addition to supporting QXP SAS or SATA expansion cards, the TS-1673AU-RP provides USB interfaces for connecting a RAID expansion enclosure. Use the QTS Storage & Snapshots Manager to easily manage NAS capacity expansion.
VJBOD
Use VJBOD (Virtual JBOD) to expand your storage capacity by utilizing the unused storage of another QNAP NAS. Up to eight QNAP NAS devices can be mounted as local drives on the TS-1673AU-RP.
Upgrade RAID capacity
Hot-swap smaller capacity drives for larger capacity drives. This allows your TS-1673AU-RP to grow with your business.
Migrate to a new NAS
Install the hard drives from your TS-1673AU-RP on a larger QNAP NAS and keep all your existing data and configurations.
Switch operating systems for optimal data integrity and reliability.
The TS-1673AU-RP also supports QuTS hero – QNAP's ZFS-based NAS operating system. Offering end-to-end data integrity, data reduction (inline deduplication, compression, and data compaction), and more, QuTS hero utilizes additional system resources to ensure an optimal environment for protecting business data.
High-performance dual 2.5GbE NAS powered by a quad-core AMD Ryzen™ processor, supporting PCIe 10GbE expandability or M.2 SSD cache for virtual applications
(Supports the QTS or QuTS hero system)
Thanks to its powerful quad-core AMD Ryzen™ V1500B processor from the V1000 series, the TS-1673AU-RP can boost virtual machine performance with up to 4 cores/8 threads at 2.2 GHz. The TS-1673AU-RP includes two 2.5GbE ports and two PCIe Gen 3 slots, providing fast network connectivity and the ability to add features and expand application capabilities. The TS-1673AU-RP also features a redundant power supply, ensuring maximum system uptime. The advanced hardware combined with comprehensive software solutions makes the TS-1673AU-RP the preferred choice for resource-intensive applications and tasks. The TS-1673AU-RP supports QTS and QuTS hero, allowing users to flexibly switch operating systems as needed.
Absolute performance with AMD Ryzen™ and up to 64GB of RAM
Powered by a quad-core AMD Ryzen™ V1500B 2.2GHz processor with AES-NI encryption acceleration and up to 64GB of DDR4 RAM, the rack-mounted TS-1673AU-RP delivers smart yet aggressive performance to run resource-intensive business applications such as VDI, R&D, private cloud, and server virtualization.
Block-based iSCSI LUN: The ideal choice for virtualization storage
The TS-1673AU-RP supports block-based iSCSI LUNs and is compatible with VMware©, Citrix©, Microsoft© Hyper-V©, and Windows Server© 2019 virtualization environments, providing an affordable, high-performance storage solution. The TS-1673AU-RP also supports VMware VAAI and Microsoft ODX to boost performance by offloading tasks from the ESXi and Hyper-V servers, respectively. The QNAP vSphere Client plug-in is also supported, improving operational efficiency and management in virtualization applications.
Optimized performance for VMware virtualization thanks to iSER
The iSER (iSCSI Extensions for RDMA) protocol boosts data transfer performance for VMware© ESXi storage and reduces the CPU load on the ESXi server. iSER support can be added to the TS-1673AU-RP by installing a QNAP QXG-10G2SF-CX4 10GbE PCIe card that uses the NVIDIA© Mellanox ConnectX-4 controller. iSER can provide a significant performance increase, offering an essential tool for optimizing demanding virtualization applications.
All-in-one server for hosting virtual machines and containers
Whatever your virtualization needs, you can rely on Virtualization Station and Container Station for comprehensive virtualization support. Use the Network & Virtual Switch app to allocate the appropriate physical network resources to virtual machines, containers, and the TS-1673AU-RP to simplify network deployment.
Upgrade to a 2.5GbE network
The TS-1673AU-RP comes with two 2.5GbE RJ45 network ports, allowing you to use existing CAT5e cables to upgrade network speeds from 1 to 2.5 Gigabit. You can also achieve 5GbE speeds using Port Aggregation. To upgrade your laptops and desktops to take advantage of high-speed networks, QNAP offers various adapters and peripherals, including a USB 3.2 Gen 1 to 5GbE adapter (model name QNA-UC5G1T) and a 5GbE PCIe expansion card (model name QXG-5G1T-111C).
Transform your network with an affordable 2.5GbE switch
You shouldn't break the bank to upgrade your network, and 2.5GbE connectivity immediately provides noticeable improvements over standard 1GbE. The QSW-1105-5T is an unmanaged switch with five 2.5GbE ports (backward compatible with 1GbE/100M) that supports CAT5e cables for connecting multiple computers and NAS devices. The QSW-1105-5T is energy-efficient, quiet, plug-and-play, and supports loop detection and blocking to provide a simple and effective high-speed network environment.
Large I/O capacities with PCIe expansion
The TS-1673AU-RP features two PCIe Gen 3 x4 slots, allowing you to add functionality with compatible PCIe cards. Using a suitable adapter, you can consolidate the two slots into a single PCIe Gen 3 x8 slot.
GPU-accelerated computing
Graphics cards are optimized for graphics processing and calculations but require significantly more power than other hardware. The TS-1673AU-RP supports low-profile, entry-level NVIDIA© GeForce© graphics cards (such as the GT 1030 or GT 1050) that do not require additional power. Installing a graphics card can boost the performance of applications such as video editing, 4K video transcoding, image processing in QTS, and virtual machine performance via GPU passthrough.
Accelerate IOPS performance with SSD caching
Adding an SSD cache to the TS-1673AU-RP is a simple way to improve IOPS performance and reduce storage volume latency. It's ideal for IOPS-intensive applications (especially databases and virtualization) and can significantly improve overall workflows. You can start, stop, or modify settings at any time to suit your needs without shutting down the system.
Migrate business data to the cloud smoothly and at a lower cost
By deploying cloud storage gateways and enabling local caching on the TS-1673AU-RP, you can perfectly utilize the cloud for data storage, backup, and restoration with low-latency access, thus providing an innovative hybrid cloud experience.
Full backup planning
The TS-1673AU-RP offers reliable and cost-effective solutions for backup planning and disaster recovery.
HBS
It brings together backup, restore and synchronization functions (using RTRR, Rsync, FTP, CIFS/SMB), in order to easily transfer data to local, remote or cloud storage spaces, such as a complete data storage or disaster recovery plan.
Snapshots for Volume and LUN
Snapshots are essential for protecting NAS data, and their block-level functionality makes them a reliable method for safeguarding against the growing threat of ransomware. The TS-1673AU-RP supports up to 256 snapshots per volume/LUN, and up to 1,024 snapshots per NAS.
VM backup
Thanks to high performance, huge storage potential, built-in virtualization solutions, and support for snapshots that record the system state at any time, the TS-1673AU-RP is perfect for backing up virtual machines.
Windows© and Mac© Backup
Use the license-free QNAP NetBak Replicator utility to back up and restore files from Windows© computers. Time Machine© is also supported for backing up Mac© computers.
High-speed VM backup solution
Thanks to Hyper Data Protector, the TS-1673AU-RP becomes an agentless backup tool for unlimited VMware© vSphere and Microsoft© Hyper-V VM backups. Hyper Data Protector includes incremental backup, global deduplication, backup scheduling, and restore compression, providing you with a cost-effective and reliable disaster recovery plan. This ensures your services operate 24/7.
Build an affordable Fibre Channel SAN environment
Typical Fibre Channel Storage Area Network (SAN) devices are often expensive. By installing a QNAP 16 Gbps Fibre Channel card (QXP-16G2FC 16Gb) in the TS-1673AU-RP, you can configure a Fibre Channel Target using the iSCSI & Fibre Channel app. Additionally, LUN masking and port binding features provide an extra layer of data security.
Flexible and economical storage expansion
QNAP provides simple storage expansion solutions. Here are several ways to increase the storage capacity of your TS-1673AU-RP to accommodate your growing data and business.
Add expansion boxes
In addition to supporting QXP SAS or SATA expansion cards, the TS-1673AU-RP provides USB interfaces for connecting a RAID expansion enclosure. Use the QTS Storage & Snapshots Manager to easily manage NAS capacity expansion.
VJBOD
Use VJBOD (Virtual JBOD) to expand your storage capacity by utilizing the unused storage of another QNAP NAS. Up to eight QNAP NAS devices can be mounted as local drives on the TS-1673AU-RP.
Upgrade RAID capacity
Hot-swap smaller capacity drives for larger capacity drives. This allows your TS-1673AU-RP to grow with your business.
Migrate to a new NAS
Install the hard drives from your TS-1673AU-RP on a larger QNAP NAS and keep all your existing data and configurations.
Switch operating systems for optimal data integrity and reliability.
The TS-1673AU-RP also supports QuTS hero – QNAP's ZFS-based NAS operating system. Offering end-to-end data integrity, data reduction (inline deduplication, compression, and data compaction), and more, QuTS hero utilizes additional system resources to ensure an optimal environment for protecting business data.
| Storage media | |
| Installed storage drives | Yes |
| Total installed storage capacity | 0 TB |
| Number of storage drives installed | 0 |
| Number of storage units supported | 16 |
| Type of storage drive installed | No |
| Supported storage drive types | HDD & SSD |
| Storage drive capacity | 0 GB |
| RAID support | Yes |
| Supported storage drive interfaces | ATA Series II, ATA Series III |
| Supported storage disk sizes | 2.5, 3.5" |
| RAID Levels | 0, 1, 5, 6, 10, 50, 60, JBOD |
| Online RAID Migration | Yes |
| Online RAID expansion | Yes |
| RAID Reconstruction | Yes |
| Hot-swappable enclosure bays | Yes |
| Supported file systems | FAT32, HFS+, NTFS, ext3, ext4 |
| Faulty block scan | Yes |
| Processor | |
| Processor family | Ryzen Embedded |
| Processor manufacturer | AMD |
| Processor model | V1500B |
| Processor frequency | 2.2 GHz |
| Processor generation | AMD Ryzen Embedded V1000 Series |
| Number of processor cores | 4 |
| Number of processor threads | 8 |
| L2 cache | 2 MB |
| L3 Cache | 4 MB |
| Graphics adapter model included | Unavailable |
| Memory | |
| Internal memory | 16 GB |
| Internal memory type | DDR4 |
| Maximum RAM supported | 32 GB |
| Memory locations | 2 |
| Memory support | UDIMM |
| Flash memory | 5000 MB |
| Network | |
| Ethernet/LAN | Yes |
| Ethernet LAN: data transfer rate | 10, 100, 1000, 2500 Mbit/s |
| DHCP Client | Yes |
| DHCP Server | Yes |
| Support for Jumbo Frames | Yes |
| iSCSI support | Yes |
| Dynamic DNS (DDNS) | Yes |
| Connectivity | |
| Number of LAN ethernet ports (RJ-45) | 2 |
| USB port | Yes |
| Number of USB 2.0 Ports | 0 |
| Number of USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports | 1 |
| Number of USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports | 1 |
| Number of USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports | 2 |
| Design | |
| Chassis type | Rack (3U) |
| Cooling type | Active |
| Product color | Black, Grey |
| Number of fans | 3 fan(s) |
| Fan diameter | 8 cm |
| Psychics | HDD, LAN, Power, Status, USB |
| representation / realization | |
| Kind | NAS |
| Device class | SMEs |
| Backup function | Yes |
| Backup functions | Cloud, iSCSI LUN |
| Audible alarm | Yes |
| Multilingual support | Yes |
| Third-party support | Yes |
| Image capture | Yes |
| Web-based management | Yes |
| Supported security algorithm | 256-bit AES, FIPS 140-2, HTTPS, SNMPv3, SSH, SSL/TLS |
| Access Control List (ACL) | Yes |
| Reset button | Yes |
| Integrated on/off button | Yes |
| Integrated iTunes Server | Yes |
| Integrated FTP server | Yes |
| Supported browsers | Apple Safari 7+, Google Chrome, Microsoft Internet Explorer 10+, Mozilla Firefox |
| System journal | Yes |
| Hot exchange | Yes |
| SMART Support | Yes |
| Shared folder | CIFS/SMB |
| Automatic recognition of computer components | Yes |
| Software | |
| Operating system installed | QNAP QTS |
| Operating system version | 5,0,0 |
| Windows operating system support | Windows 10, Windows 7, Windows 8 |
| Linux operating system support | Yes |
| Mac operating system support | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS |
| Server operating system support | Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64, Windows Server 2016, Windows Server 2016 x64, Windows Server 2019 |
| Support for other operating systems | Solaris 10 |
| Power | |
| Power supply location | Integrated |
| Power supply unit (PSU) capacity | 550 W |
| Number of power supplies | 2 |
| Typical electricity consumption | 97.34 W |
| Energy consumption (in standby mode) | 47.75 W |
| AC input voltage | 100-240V |
| AC input frequency | 50-60 Hz |
| Fan voltage | 12V |
| Weight and dimensions | |
| Width | 482 mm |
| Depth | 425 mm |
| Height | 132 mm |
| Weight | 12 kg |
| Package weight | 17.1 kg |
| Package contents | |
| Cables included | Sector, LAN (RJ-45) |
| Number of screws | 64 |
| Environmental conditions | |
| Operating temperature | 0 - 40 °C |
| Operating relative humidity (HH) | 5 - 95% |
| Off-temperature | -20 - 70 °C |
| Logistics data | |
| Harmonized System Code | 84714100 |
