Description
Gigabit speeds: Take your data to the next level
The GSW-1657 is a 16-port Gigabit Ethernet switch that offers a high-performance, cost-effective, and easy-to-use upgrade to boost your network speeds up to 1000Mbps. Increase your backbone network speed to a blazing 32Gbps and bring all your computers up to Gigabit speeds.
Need a large bandwidth? No problem.
What happens if you have multiple users connecting to multimedia applications simultaneously? Don't worry, the GSW-1657 makes transferring large files faster and easier. Transfer your CGI, CAD, video, or other large multimedia files instantly over the network without lag.
Based on standards
The GSW-1657 features a non-blocking switching architecture that forwards and filters packets at maximum wire speed for maximum throughput. With automatic MAC address learning and aging, IEEE 802.3x flow control for full-duplex mode, and backpressure for half-duplex mode, you have powerful features for sending your data across the network.
Plug and Play, flexible and easy
The GSW-1657 is plug-and-play and requires no configuration. Equipped with automatic MDI/MDI-X cable detection on all ports, it eliminates the need for crossover cables or uplink ports. Each port can be used as a general port or uplink port, and each port simply connects to a server, hub, router, or switch using a straight or crossover cable. Diagnostic LEDs display link status and activity, allowing you to quickly detect and correct problems on your network.
- 16 Gigabit Ethernet ports
- Cable transmission and reception at speeds of 10/100/1000Mbps
- Jumbo frame transfer rate of 10K to increase data
- Supports 8K MACs with self-learning and self-aging capabilities
- QoS control for traffic prioritization and bandwidth management
- IEEE 802.3x flow control protects against packet loss for reliable data transmission
- 60 cm metal case
The GSW-1657 is a 16-port Gigabit Ethernet switch that offers a high-performance, cost-effective, and easy-to-use upgrade to boost your network speeds up to 1000Mbps. Increase your backbone network speed to a blazing 32Gbps and bring all your computers up to Gigabit speeds.
Need a large bandwidth? No problem.
What happens if you have multiple users connecting to multimedia applications simultaneously? Don't worry, the GSW-1657 makes transferring large files faster and easier. Transfer your CGI, CAD, video, or other large multimedia files instantly over the network without lag.
Based on standards
The GSW-1657 features a non-blocking switching architecture that forwards and filters packets at maximum wire speed for maximum throughput. With automatic MAC address learning and aging, IEEE 802.3x flow control for full-duplex mode, and backpressure for half-duplex mode, you have powerful features for sending your data across the network.
Plug and Play, flexible and easy
The GSW-1657 is plug-and-play and requires no configuration. Equipped with automatic MDI/MDI-X cable detection on all ports, it eliminates the need for crossover cables or uplink ports. Each port can be used as a general port or uplink port, and each port simply connects to a server, hub, router, or switch using a straight or crossover cable. Diagnostic LEDs display link status and activity, allowing you to quickly detect and correct problems on your network.
- 16 Gigabit Ethernet ports
- Cable transmission and reception at speeds of 10/100/1000Mbps
- Jumbo frame transfer rate of 10K to increase data
- Supports 8K MACs with self-learning and self-aging capabilities
- QoS control for traffic prioritization and bandwidth management
- IEEE 802.3x flow control protects against packet loss for reliable data transmission
- 60 cm metal case
| Management characteristics | |
| Switch type | Unmanaged |
| Quality of Service (QoS) | Yes |
| Connectivity | |
| Number of basic switching RJ-45 Ethernet ports | 16 |
| Basic switching RJ-45 Ethernet port type | Gigabit Ethernet (10/100/1000) |
| Network | |
| Network standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| 10G support | No |
| Copper Ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Supported cable types | Cat5, Cat6, Cat7 |
| Full duplex | Yes |
| Flow control assistance | Yes |
| Auto MDI/MDI-X | Yes |
| Data transmission | |
| MAC address book | 8192 entries |
| Switching capacity | 32 Gbit/s |
| Recording and retransmission | Yes |
| Support for Jumbo Frames | Yes |
| Giant frames | 10000 |
| Packet transfer rate (1 Gbps) | 1,488,000 pps |
| Packet transfer rate (100 Mbps) | 148,000 pps |
| Packet transfer rate (10 Gbps) | 14880 pps |
| Packet cache memory | 0.5 MB |
| Design | |
| Mounting grid | Yes |
| Product color | Black, Grey |
| Psychics | Activity, Connection |
| Power | |
| AC input voltage | 100-240V |
| AC input frequency | 50-60 Hz |
| Input current | 0.6 A |
| Typical electricity consumption | 13.3 W |
| PoE (Power over Ethernet) | |
| Ethernet connection, supporting power delivery via this port (PoE) | No |
| Environmental conditions | |
| Operating temperature | 0 - 45 °C |
| Off-temperature | -40 - 70 °C |
| Operating relative humidity (HH) | 10-90% |
| Relative humidity level (storage) | 10-90% |
| Weight and dimensions | |
| Width | 140 mm |
| Depth | 440 mm |
| Height | 44 mm |
| Weight | 1.48 kg |
| Package contents | |
| Cables included | Sector |
| Quick Start Guide | Yes |
| Packaging information | |
| lifting hooks included | Yes |
| Package width | 224 mm |
| Package depth | 486 mm |
| Package height | 77 mm |
| Package weight | 2.15 kg |
| Certificate | |
| Certification | FCC, CE |
| Logistics data | |
| Width of the main (external) locker | 405 mm |
| Length of the main (external) locker | 500 mm |
| Height of the main (external) locker | 240 mm |
| Harmonized System Code | 85176990 |
| Gross weight of the main (external) locker | 11.8 kg |
