Description
Versatility thanks to 16 10/100BASE-TX ports
10/100Mbps-Full/Half-duplex, auto-negotiation, auto-MDI/MDIX
Supports 8K MACs with self-learning and self-aging capabilities.
QoS control for traffic prioritization and bandwidth management
IEEE 802.3x flow control protects against packet loss for reliable data transmission
60 cm metal case
Internal power supply
Minimizes carbon footprint with its advanced energy-saving technology (IEEE 802.3az)
10/100Mbps-Full/Half-duplex, auto-negotiation, auto-MDI/MDIX
Supports 8K MACs with self-learning and self-aging capabilities.
QoS control for traffic prioritization and bandwidth management
IEEE 802.3x flow control protects against packet loss for reliable data transmission
60 cm metal case
Internal power supply
Minimizes carbon footprint with its advanced energy-saving technology (IEEE 802.3az)
| Management characteristics | |
| Switch type | Unmanaged |
| Connectivity | |
| Number of basic switching RJ-45 Ethernet ports | 16 |
| Basic switching RJ-45 Ethernet port type | Fast Ethernet (10/100) |
| Number of SFP modules installed | 0 |
| Number of SFP+ modules installed | 0 |
| Network | |
| Network standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| 10G support | No |
| Copper Ethernet cabling technology | 10BASE-T, 100BASE-TX |
| Supported cable types | Cat5 |
| Full duplex | Yes |
| Data transmission | |
| MAC address book | 8192 entries |
| Switching capacity | 3.2 Gbit/s |
| Recording and retransmission | Yes |
| Protocols | |
| Switching protocol | CSMA/CD |
| Design | |
| Mounting grid | Yes |
| Stackable | No |
| Product color | Gray |
| Psychics | Activity, LAN, Connection, Energy |
| representation / realization | |
| Buffer size | 160 KB |
| Power | |
| AC input voltage | 100-240V |
| AC input frequency | 50-60 Hz |
| Typical electricity consumption | 6.2 W |
| PoE (Power over Ethernet) | |
| Ethernet connection, supporting power delivery via this port (PoE) | No |
| Environmental conditions | |
| Operating temperature | 0 - 40 °C |
| Off-temperature | -40 - 70 °C |
| Operating relative humidity (HH) | 10-90% |
| Relative humidity level (storage) | 5 - 95% |
| Weight and dimensions | |
| Width | 44 mm |
| Depth | 208 mm |
| Height | 440 mm |
| Weight | 2.6 kg |
| Package contents | |
| Cables included | Sector |
| Quick Start Guide | Yes |
| Packaging information | |
| Wall mounting kit | Yes |
| Package width | 308 mm |
| Package depth | 94 mm |
| Package height | 550 mm |
| Package weight | 2.7 kg |
| Certificate | |
| Certification | THIS RoHS |
| Logistics data | |
| Country of origin | China |
| Harmonized System Code | 85176990 |
