Description
Intel© Trusted Execution Technology
It is a set of hardware extensions to Intel processors and chipsets, which strengthen the platform for the digital office through security capabilities such as an MLE (Measured Launch Environment) environment and execution protected. It achieves this by enabling an environment where applications can run in their own space, away from other software on the system.
Intel© Virtualization Technology for Distributed I/O (VT-d)
Intel© VT Virtualization Technology for Distributed I/O (VT-d) extends existing support for Intel© VT Virtualization Technology for IA-32 (VT-x) and Itanium© (VT-i) by adding new support for virtualizing I/O devices. Intel© VT virtualization technology for distributed I/O can help users improve the security and reliability of their systems, as well as the performance of I/O devices in virtualized environments.
Intel© Virtualization Technology (VT-x)
Intel© VT Virtualization Technology (VT-x) allows a hardware platform to split into multiple virtual platforms. It makes it possible to reinforce the ease of administration of the fleet, in order to limit service interruptions and prevent the resulting drops in productivity, by isolating the operations concerned on an ad hoc partition.
Intel© 64
The Intel© 64 architecture delivers 64-bit computing on servers, workstations, PCs and mobiles when the platform is combined with compatible software.¹ The Intel© 64 architecture improves performance by enabling systems to overcome the 4 GB barrier to address virtual and physical memory.
Intel© Clear Video HD Technology
Intel© Clear Video HD Technology, like its predecessor Intel© Clear Video, is a suite of decoding and image processing technologies included in integrated graphics processors. It improves video playback by providing a cleaner, sharper image, more natural, vivid and accurate colors, and increased image stability. Intel© Clear Video HD technology improves video quality with richer colors and more realistic skin tones.
Hidden
The processor cache is a high-speed memory area located on the processor. Intel© Smart Cache is the architecture that allows all cores to dynamically share access to the last-level cache.
New Intel© AES instructions
With the new AES-NI (Advanced Encryption Standard New Instructions), data encryption and decryption is fast and secure. AES-NI instructions are useful for a wide range of cryptographic applications, for example: bulk encryption/decryption, authentication, random number generation, and authenticated encryption applications.
inactivity states
Idle states, “C” states, are used to save power when the processor is idle. C0 corresponds to the operating state, when the processor has useful activity. C1 is the first inactivity state, C2 the second, and so on. The higher the C status number, the more energy saving actions implemented.
Intel© Turbo Boost Technology
Intel© Turbo Boost technology dynamically increases the processor frequency as needed, taking advantage of the thermal and electrical reserve to provide extra speed when needed and better energy efficiency when not.
Maximum Turbo Frequency
The Max Turbo Frequency is the maximum frequency of a single core at which the processor is capable of operating using Intel© Turbo Boost Technology and, if present, the Intel© Thermal Velocity Boost feature. Frequency is measured in gigahertz (GHz) or billions of cycles per second.
Lock bit
The lock bit is a hardware security feature that can reduce exposure to viruses and malicious code attacks and prevent harmful software from running and spreading on the server or network.
Intel© Hyper-Threading Technology
Intel© Hyper-Threading technology provides two execution units per physical core. Multi-process applications can do more work in parallel and thus complete tasks more quickly.
Instruction sets
Instruction set refers to the set of basic commands and instructions that a microprocessor understands and can execute. The value shown represents the Intel© instruction set with which this processor is compatible.
Intel© Quick Sync Video Technology
Intel© Quick Sync Video technology enables fast video conversion for portable media players, online sharing, and video directing and editing.
Intel© VT-x virtualization technology with paging tables (Extended Page Tables)
Intel© VT (VT-x) virtualization technology with Extended Page Tables, also known as Second Level Address Translation (SLAT), accelerates memory-intensive virtualized applications. Extended Page Tables on Intel© Virtualization Technology platforms reduces memory overhead and power consumption while increasing battery life with hardware-optimized table management paging.
Enhanced Intel SpeedStep© Technology
Enhanced Intel SpeedStep© technology is a sophisticated way to enable high performance while meeting the power conservation needs of mobile systems. Classic Intel SpeedStep© technology together switches voltage and frequency between high and low levels based on CPU load. Enhanced Intel SpeedStep© technology builds on this architecture and uses design strategies such as separation between voltage and frequency changes, and clock partitioning and recovery.
Secure Key
Intel© Secure Key is a number generator that creates truly random numbers, helping to strengthen encryption algorithms.
Intel © Speed Shift Technologies
Intel© Speed Shift Technology uses hardware-controlled P-states to significantly accelerate responsiveness with transient (low-duration) single-threaded workloads, such as web browsing, by allowing the processor to select the best frequency more quickly operating voltage and voltage to achieve optimal performance and energy efficiency.
Intel© Deep Learning Boost (Intel© DL Boost)
A new set of processor technologies designed to accelerate the use of deep learning in AI. It extends the Intel AVX-512 instructions with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance compared to previous generations.
Extensions to the instruction set
Instruction set extensions refer to additional instructions that improve performance when the same operations are performed on multiple data objects. These extensions may include SSE (Streaming SIMD Extensions) and AVX (Advanced Vector Extensions).
Intel© Thermal Velocity Boost frequency
Intel© Thermal Velocity Boost (Intel© TVB) is a feature that automatically and timely increases the clock frequency beyond the single-core and multi-core frequencies of Intel© Turbo Boost Technology based on the temperature at which it is operating the processor below its maximum temperature and the available turbo power budget. The frequency gain and duration depend on the workload, the capabilities of the processor and its cooling solution.
Intel© Turbo Boost Max 3.0 Technology Frequency
Intel© Turbo Boost Max 3.0 technology identifies the highest performing core(s) on a processor and provides increased performance on that core by increasing frequency as needed by taking advantage of thermal and power reserve. The frequency of Intel© Turbo Boost Max Technology 3.0 is the clock frequency of the processor when operating in this mode.
Intel© Turbo Boost Max 3.0 technology
Intel© Turbo Boost Max 3.0 technology identifies the highest performing core(s) on a processor and provides increased performance on that core by increasing frequency as needed by taking advantage of thermal and power reserve.
Thermal monitoring technologies
Monitoring technologies protect the processor package and system from thermal failures through thermal management features. An integrated digital thermal sensor (DTS) detects core temperature and thermal management features reduce package power consumption, and therefore temperature, as needed to stay within normal operating limits.
Intel© Thermal Velocity Boost
Intel© Thermal Velocity Boost (Intel© TVB) is a feature that automatically and timely increases the clock frequency beyond the single-core and multi-core frequencies of Intel© Turbo Boost Technology based on the temperature at which it is operating the processor below its maximum temperature and the available turbo power budget. The frequency gain and duration depend on the workload, the capabilities of the processor and its cooling solution.
Intel© Volume Management Device (VMD)
Intel© Volume Management Device (VMD) provides a robust common method for managing power-on swapping and LEDs of NVMe SSD storage drives.
Intel© Gaussian & Neural Accelerator
The Intel© Gaussian & Neural Accelerator (GNA) is an ultra-low-voltage accelerator block designed to run audio and speed-centric AI workloads. Intel© Gaussian & Neural Accelerator is designed to run audio neural networks at very low voltage, while simultaneously relieving the CPU of this workload.
Mode-based Execute Control (MBE)
Mode-based Execute Control (MBE) can more reliably verify and ensure code integrity at the kernel level.
Intel© Stable Image Platform Program
The Intel© Stable Image Platform program aims to make no changes to key platform components and drivers for at least 15 months or until the next generational release, reducing complexity and enabling IT to effectively manage their IT endpoints.
Intel© Boot Guard
Intel© Device Protection technology with Boot Guard helps protect the system's pre-OS environment from virus and malware attacks.
Intel© Control-Flow Enforcement Technology
CET - Intel Control-flow Enforcement Technology (CET) helps protect against inappropriate use of code fragments through control flow control-flow back-oriented programming (ROP) attacks.
It is a set of hardware extensions to Intel processors and chipsets, which strengthen the platform for the digital office through security capabilities such as an MLE (Measured Launch Environment) environment and execution protected. It achieves this by enabling an environment where applications can run in their own space, away from other software on the system.
Intel© Virtualization Technology for Distributed I/O (VT-d)
Intel© VT Virtualization Technology for Distributed I/O (VT-d) extends existing support for Intel© VT Virtualization Technology for IA-32 (VT-x) and Itanium© (VT-i) by adding new support for virtualizing I/O devices. Intel© VT virtualization technology for distributed I/O can help users improve the security and reliability of their systems, as well as the performance of I/O devices in virtualized environments.
Intel© Virtualization Technology (VT-x)
Intel© VT Virtualization Technology (VT-x) allows a hardware platform to split into multiple virtual platforms. It makes it possible to reinforce the ease of administration of the fleet, in order to limit service interruptions and prevent the resulting drops in productivity, by isolating the operations concerned on an ad hoc partition.
Intel© 64
The Intel© 64 architecture delivers 64-bit computing on servers, workstations, PCs and mobiles when the platform is combined with compatible software.¹ The Intel© 64 architecture improves performance by enabling systems to overcome the 4 GB barrier to address virtual and physical memory.
Intel© Clear Video HD Technology
Intel© Clear Video HD Technology, like its predecessor Intel© Clear Video, is a suite of decoding and image processing technologies included in integrated graphics processors. It improves video playback by providing a cleaner, sharper image, more natural, vivid and accurate colors, and increased image stability. Intel© Clear Video HD technology improves video quality with richer colors and more realistic skin tones.
Hidden
The processor cache is a high-speed memory area located on the processor. Intel© Smart Cache is the architecture that allows all cores to dynamically share access to the last-level cache.
New Intel© AES instructions
With the new AES-NI (Advanced Encryption Standard New Instructions), data encryption and decryption is fast and secure. AES-NI instructions are useful for a wide range of cryptographic applications, for example: bulk encryption/decryption, authentication, random number generation, and authenticated encryption applications.
inactivity states
Idle states, “C” states, are used to save power when the processor is idle. C0 corresponds to the operating state, when the processor has useful activity. C1 is the first inactivity state, C2 the second, and so on. The higher the C status number, the more energy saving actions implemented.
Intel© Turbo Boost Technology
Intel© Turbo Boost technology dynamically increases the processor frequency as needed, taking advantage of the thermal and electrical reserve to provide extra speed when needed and better energy efficiency when not.
Maximum Turbo Frequency
The Max Turbo Frequency is the maximum frequency of a single core at which the processor is capable of operating using Intel© Turbo Boost Technology and, if present, the Intel© Thermal Velocity Boost feature. Frequency is measured in gigahertz (GHz) or billions of cycles per second.
Lock bit
The lock bit is a hardware security feature that can reduce exposure to viruses and malicious code attacks and prevent harmful software from running and spreading on the server or network.
Intel© Hyper-Threading Technology
Intel© Hyper-Threading technology provides two execution units per physical core. Multi-process applications can do more work in parallel and thus complete tasks more quickly.
Instruction sets
Instruction set refers to the set of basic commands and instructions that a microprocessor understands and can execute. The value shown represents the Intel© instruction set with which this processor is compatible.
Intel© Quick Sync Video Technology
Intel© Quick Sync Video technology enables fast video conversion for portable media players, online sharing, and video directing and editing.
Intel© VT-x virtualization technology with paging tables (Extended Page Tables)
Intel© VT (VT-x) virtualization technology with Extended Page Tables, also known as Second Level Address Translation (SLAT), accelerates memory-intensive virtualized applications. Extended Page Tables on Intel© Virtualization Technology platforms reduces memory overhead and power consumption while increasing battery life with hardware-optimized table management paging.
Enhanced Intel SpeedStep© Technology
Enhanced Intel SpeedStep© technology is a sophisticated way to enable high performance while meeting the power conservation needs of mobile systems. Classic Intel SpeedStep© technology together switches voltage and frequency between high and low levels based on CPU load. Enhanced Intel SpeedStep© technology builds on this architecture and uses design strategies such as separation between voltage and frequency changes, and clock partitioning and recovery.
Secure Key
Intel© Secure Key is a number generator that creates truly random numbers, helping to strengthen encryption algorithms.
Intel © Speed Shift Technologies
Intel© Speed Shift Technology uses hardware-controlled P-states to significantly accelerate responsiveness with transient (low-duration) single-threaded workloads, such as web browsing, by allowing the processor to select the best frequency more quickly operating voltage and voltage to achieve optimal performance and energy efficiency.
Intel© Deep Learning Boost (Intel© DL Boost)
A new set of processor technologies designed to accelerate the use of deep learning in AI. It extends the Intel AVX-512 instructions with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance compared to previous generations.
Extensions to the instruction set
Instruction set extensions refer to additional instructions that improve performance when the same operations are performed on multiple data objects. These extensions may include SSE (Streaming SIMD Extensions) and AVX (Advanced Vector Extensions).
Intel© Thermal Velocity Boost frequency
Intel© Thermal Velocity Boost (Intel© TVB) is a feature that automatically and timely increases the clock frequency beyond the single-core and multi-core frequencies of Intel© Turbo Boost Technology based on the temperature at which it is operating the processor below its maximum temperature and the available turbo power budget. The frequency gain and duration depend on the workload, the capabilities of the processor and its cooling solution.
Intel© Turbo Boost Max 3.0 Technology Frequency
Intel© Turbo Boost Max 3.0 technology identifies the highest performing core(s) on a processor and provides increased performance on that core by increasing frequency as needed by taking advantage of thermal and power reserve. The frequency of Intel© Turbo Boost Max Technology 3.0 is the clock frequency of the processor when operating in this mode.
Intel© Turbo Boost Max 3.0 technology
Intel© Turbo Boost Max 3.0 technology identifies the highest performing core(s) on a processor and provides increased performance on that core by increasing frequency as needed by taking advantage of thermal and power reserve.
Thermal monitoring technologies
Monitoring technologies protect the processor package and system from thermal failures through thermal management features. An integrated digital thermal sensor (DTS) detects core temperature and thermal management features reduce package power consumption, and therefore temperature, as needed to stay within normal operating limits.
Intel© Thermal Velocity Boost
Intel© Thermal Velocity Boost (Intel© TVB) is a feature that automatically and timely increases the clock frequency beyond the single-core and multi-core frequencies of Intel© Turbo Boost Technology based on the temperature at which it is operating the processor below its maximum temperature and the available turbo power budget. The frequency gain and duration depend on the workload, the capabilities of the processor and its cooling solution.
Intel© Volume Management Device (VMD)
Intel© Volume Management Device (VMD) provides a robust common method for managing power-on swapping and LEDs of NVMe SSD storage drives.
Intel© Gaussian & Neural Accelerator
The Intel© Gaussian & Neural Accelerator (GNA) is an ultra-low-voltage accelerator block designed to run audio and speed-centric AI workloads. Intel© Gaussian & Neural Accelerator is designed to run audio neural networks at very low voltage, while simultaneously relieving the CPU of this workload.
Mode-based Execute Control (MBE)
Mode-based Execute Control (MBE) can more reliably verify and ensure code integrity at the kernel level.
Intel© Stable Image Platform Program
The Intel© Stable Image Platform program aims to make no changes to key platform components and drivers for at least 15 months or until the next generational release, reducing complexity and enabling IT to effectively manage their IT endpoints.
Intel© Boot Guard
Intel© Device Protection technology with Boot Guard helps protect the system's pre-OS environment from virus and malware attacks.
Intel© Control-Flow Enforcement Technology
CET - Intel Control-flow Enforcement Technology (CET) helps protect against inappropriate use of code fragments through control flow control-flow back-oriented programming (ROP) attacks.
| Processor | |
| Processor family | Intel® Core™ i9 |
| Number of processor cores | 24 |
| Processor socket (processor socket) | LGA 1700 |
| Box | Yes |
| Cooler included | No |
| Processor manufacturer | Intel |
| Processor model | i9-13900KS |
| Processor operating modes | 64-bit |
| Generation of processors | 13th generation Intel® Core™ i9 processors |
| Number of CPU threads | 32 |
| Performance Cores | 8 |
| Effective hearts | 16 |
| Turbo processor frequency | 6GHz |
| Supercharging frequency of high-performance hearts | 5.4GHz |
| Base frequency of high-performance hearts | 3.2GHz |
| Supercharging frequency of efficient hearts | 4.3GHz |
| Base frequency of effective hearts | 2.4GHz |
| CPU cache | 36 MB |
| Processor Cache Type | Smart Cache |
| Core CPU Power | 150W |
| Maximum turbo power | 253W |
| Stepping | B0 |
| Bus type | DMI4 |
| Maximum number of DMI channels | 8 |
| Memory bandwidth supported by processor (max) | 89.6 GB/s |
| Processor code name | Raptor Lake |
| Processor ARK ID | 232167 |
| Memory | |
| Memory Channels | Dual channel |
| Maximum internal memory supported by the processor | 192 GB |
| Memory types supported by the processor | DDR4-SDRAM, DDR5-SDRAM |
| ECC | Yes |
| Non-ECC | Yes |
| Memory bandwidth (max) | 89.6 GB/s |
| Chart | |
| Integrated graphics card | Yes |
| Separate graphics card adapter | No |
| Graphics adapter model included | Intel UHD Graphics 770 |
| Separate graphics adapter model | Unavailable |
| Supported graphics card outputs | Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1 |
| Integrated graphics card base frequency | 300 MHz |
| Dynamic frequency (max) of integrated graphics card | 1650 MHz |
| Number of displays supported by the integrated graphics card | 4 |
| DirectX version of integrated graphics card | 12.0 |
| OpenGL version of integrated graphics card | 4.5 |
| Maximum resolution (DisplayPort) of the integrated graphics card | 7680 x 4320 pixels |
| Maximum resolution (eDP - Integrated Flat Panel) | 5120 x 3200 pixels |
| Maximum resolution (HDMI) of integrated graphics card | 4096 x 2160 pixels |
| Refresh rate at maximum resolution (DisplayPort) | 60Hz |
| Refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 120Hz |
| Refresh rate at maximum resolution (HDMI) | 60Hz |
| Integrated graphics card ID | 0xA780 |
| Number of execution units | 32 |
| Multi-format codec engines | 2 |
| Features | |
| Lock bit | Yes |
| Idle States | Yes |
| Thermal monitoring technologies | Yes |
| Market segment | Desk |
| Terms of use | PC/Client/Tablet |
| Maximum number of PCI Express lanes | 20 |
| PCI Express slot version | 5.0, 4.0 |
| PCI Express configurations | 1x16+1x4, 2x8+1x4 |
| Supported instruction set | SSE4.1, SSE4.2, AVX 2.0 |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Built-in options available | No |
| Revision of the DMI (Direct Media Interface) | 4.0 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
| Special processor features | |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Quick Sync Video Technology | Yes |
| Intel Clear Video Technology HD | Yes |
| New Intel® AES Instructions (Intel® AES-NI) | Yes |
| Intel Advanced SpeedStep Technology | Yes |
| Intel® Trusted Execution Technology | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® Thermal Velocity Boost | Yes |
| Intel® Adaptive Boost Technology | Yes |
| Intel® Turbo Boost Max Technology 3.0 frequency | 5.8GHz |
| Intel® Gaussian and Neural Accelerator (Intel® GNA) 3.0 | Yes |
| Intel® Thermal Velocity Boost Frequency | 6GHz |
| Intel® Control-flow Enforcement Technology (CET) | Yes |
| Intel® Thread Director | Yes |
| Intel® VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Security Key | Yes |
| Intel® Active Management Technology (Intel® AMT) | Yes |
| Intel® Stable Image Platform Program (SIPP) | Yes |
| Intel® Guard SE | Yes |
| Intel® 64 | Yes |
| Intel® Vitalization Technology (VT-x) | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Turbo Boost Max Technology 3.0 | Yes |
| Intel® Boot Guard | Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® vPro? Platform Eligibility | Yes |
| Intel® Standard Management (ISM) | Yes |
| Intel® One-Click Recovery | Yes |
| Intel® Stable Computing Platforms Program (SIPP) | Yes |
| Intel® Platform Remote Erase (RPE) | Yes |
| Intel® Virtualization Technology with Redirect Protection (VT-rp) | Yes |
| Intel vPro® Enterprise Platform Eligibility | Yes |
| Intel® Threat Detection Technology (TDT) | Yes |
| Intel Hardware Protection Eligibility | Yes |
| Full Memory Encryption by Intel® - Multiple Key | Yes |
| Intel vPro® Essentials Platform Eligibility | Yes |
| Environmental conditions | |
| Tjunction | 100°C |
| Technical details | |
| OpenCL version | 3.0 |
| Target market | Gaming, Content Creation |
| Release date | Q1'23 |
| State | Launched |
| Logistics data | |
| Harmonized System Code | 8542310001 |
| Packaging information | |
| Type of packaging | Retail Box |
| Other features | |
| L2 cache | 32768 KB |
| Maximum internal memory | 192 GB |
| Graphics output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
