Description
Intelligent performance and design
A smart, compact format, optimized for performance and space-saving.
A smart, compact format, optimized for performance and space-saving.
| Processor | |
| Processor family | Intel® Core™ i7 |
| Processor manufacturer | Intel |
| Processor model | i7-14700 |
| Processor generation | Intel Core i7-14xxx |
| Number of processor cores | 20 |
| Number of processor threads | 28 |
| Turbo processor frequency | 5.4 GHz |
| Performance cores | 8 |
| Efficient Hearts | 12 |
| Maximum Turbo Frequency of Performance Cores | 5.3 GHz |
| Maximum Turbo Frequency of Efficient Cores | 4.2 GHz |
| Base frequency of high-performance cores | 2.1 GHz |
| Baseline frequency of effective hearts | 1.5 GHz |
| Processor cache memory | 33 MB |
| Processor cache type | Smart Cache |
| Number of processors installed | 1 |
| Base processor power | 65 W |
| Maximum turbo power | 219 W |
| Memory | |
| Internal memory | 16 GB |
| Maximum internal memory | 64 GB |
| Internal memory type | DDR5-SDRAM |
| Memory configuration (slot x size) | 1 x 16 GB |
| Memory locations | 2x SO-DIMM |
| Memory data transfer rate | 5600 MT/s |
| storage media | |
| Total storage capacity | 512 GB |
| Optical reader | No |
| Storage media | SSD |
| Total SSD capacity | 512 GB |
| Number of SSDs installed | 1 |
| Solid State Drive (SSD) capacity | 512 GB |
| Solid State Drive (SSD) interface | PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| SSD performance class | 40 |
| Chart | |
| Separate graphics card adapter | No |
| Integrated graphics card | Yes |
| Separate graphics adapter model | Unavailable |
| Graphics adapter model included | Intel UHD Graphics 770 |
| Integrated GPU manufacturer | Intel |
| Integrated graphics adapter family | Intel® UHD Graphics |
| Network | |
| Ethernet/LAN | Yes |
| Wi-Fi | No |
| Ethernet LAN: data transfer rate | 10, 1000, 2500, 100 Mbps |
| Connectivity | |
| Number of USB 2.0 Ports | 4 |
| Number of USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports | 3 |
| Number of USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports | 0 |
| Number of USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports | 2 |
| Number of USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports | 0 |
| Number of Thunderbolt 3 ports | 0 |
| Number of USB 3.2 Gen. 2x2 Type-C ports | 1 |
| PowerShare | Yes |
| Number of PowerShare USB ports | 1 |
| Number of DisplayPort interfaces | 3 |
| DisplayPort version | 1.4 |
| Number of LAN ethernet ports (RJ-45) | 1 |
| Headphone output | 1 |
| Headset/Microphone Combo Port | Yes |
| Number of SATA III connectors | 3 |
| Extension connectors | |
| PCI Express x4 slot(s) (Gen 3.x) | 1 |
| PCI Express x16 slots (Gen. 4.x) | 1 |
| Design | |
| Chassis type | SFF |
| Product color | Black |
| Installation included | vertical |
| Anti-theft cable port | Yes |
| Cable lock location type | Kensington |
| Intel® vPro™ Platform Eligibility | Yes |
| representation / realization | |
| Product type | Workstation |
| market position | Professional |
| Motherboard chipset | Intel W680 |
| Audio system | Waves MaxxAudio |
| TPM (Trusted Platform Module) chip | Yes |
| Software | |
| Operating system installed | Windows 11 Pro |
| Operating system architecture | 64-bit |
| Operating system language | German, Dutch, English, French, Italian |
| Testing software | Activate Your Microsoft 365 For A 30 Day Trial |
| Power | |
| Power supply | 300 W |
| Power supply input voltage | 90 - 264 V |
| Power supply input frequency | 47/63 Hz |
| 80 PLUS Certification | 80 PLUS Platinum |
| Environmental conditions | |
| Operating temperature | 10 - 35 °C |
| Off-temperature | -40 - 65 °C |
| Operating relative humidity (HH) | 20-80% |
| Relative humidity level (storage) | 5 - 95% |
| Operating altitude | 0 - 3048 m |
| Non-operational altitude | 0 - 10668 m |
| Vibrations during operation | 0.26 G |
| Vibrations not functioning | 1.37 G |
| Shock, out of order | 105 G |
| Weight and dimensions | |
| Width | 92.6 mm |
| Depth | 292.8 mm |
| Height | 290 mm |
| Weight | 5.38 kg |
| Package contents | |
| Cables included | Sector |
| Carbon footprint | |
| Total carbon footprint (kg of CO2e) | 439 |
| Total carbon emissions, standard deviation (kg CO2e) | 132 |
| Carbon emissions, manufacturing (kg of CO2e) | 232.76 |
| Carbon emissions, logistics (kg CO2e) | 15.4 |
| Carbon emissions, energy use (kg of CO2e) | 188 |
| End-of-life carbon emissions (kg CO2e) | 3.58 |
| Total carbon emissions, excluding the use phase (kg CO2e) | 251 |
| PAIA version | 1.3.1, 2022 |
| Screen | |
| Screen included | No |
