Description
The balance between scalability and performance
Flexible dual-socket tower server for enterprise application workloads outside the traditional datacenter.
Flexible dual-socket tower server for enterprise application workloads outside the traditional datacenter.
| Processor | |
| Processor family | Intel® Xeon® Silver |
| Processor manufacturer | Intel |
| Processor model | 4309Y |
| Processor frequency | 2.8 GHz |
| Processor generation | 3rd Generation Intel® Xeon® Scalable |
| Turbo processor frequency | 3.6 GHz |
| Baseline frequency of effective hearts | 0.0028 GHz |
| Base frequency of high-performance cores | 2.8 GHz |
| Number of processor cores | 8 |
| Processor cache memory | 12 MB |
| Number of processors installed | 1 |
| Maximum internal memory supported by the processor | 32 GB |
| Memory | |
| Internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 64 GB |
| Cache memory type | Registered (buffered) |
| Memory level | 2 |
| Memory locations | 16x DIMM |
| Memory configuration (slot x size) | 1 x 16 GB |
| Memory data transfer rate | 3200 MT/s |
| storage media | |
| Total storage capacity | 480 GB |
| RAID support | Yes |
| Optical reader | No |
| Number of SSDs installed | 1 |
| Solid State Drive (SSD) capacity | 480 GB |
| Solid State Drive (SSD) interface | SATA III |
| SSD dimensions | 2.5" |
| Supported SSD sizes | 3.5" |
| Number of SSD cards supported | 8 |
| Supported RAID controllers | PERC H755 |
| Hot-plug support | Yes |
| Internal bays | 8 |
| Supported storage drive interfaces | SAS, SATA |
| Disk recordings per day (DWPD) | 1 |
| Storage drive adapter included | Yes |
| Storage drive adapter type | 2.5" - 3.5" |
| Chart | |
| Integrated graphics card | No |
| Graphics adapter model included | Unavailable |
| Network | |
| Ethernet/LAN | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet interface type | Gigabit Ethernet |
| Connectivity | |
| Number of LAN ethernet ports (RJ-45) | 2 |
| Number of USB 2.0 Ports | 2 |
| Number of USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports | 2 |
| Number of VGA (D-Sub) ports | 1 |
| Number of serial ports | 1 |
| Quantity of power cables | 1 |
| Design | |
| Chassis type | Tower (5U) |
| Product color | Black |
| Bezel | Yes |
| representation / realization | |
| Remote administration | iDRAC9, Enterprise 15G |
| Software | |
| Operating system installed | No |
| Compatible operating systems | Canonical Ubuntu Server LTS ● Citrix Hypervisor Microsoft Windows Server with Hyper-V Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware ESXi |
| Power | |
| Redundant Power Supply (RPS) | No |
| Power supply | 700 W |
| Number of main power supplies | 1 |
| Power supply input voltage | 200-240 V |
| Power cord length | 2 m |
| Power cable connector 1 | C13 Coupler |
| Power cord current | 10 A |
| Environmental conditions | |
| Operating temperature | 10 - 35 °C |
| Off-temperature | -40 - 65 °C |
| Relative humidity level (storage) | 5 - 95% |
| Operating altitude | 0 - 3048 m |
| Non-operational altitude | 0 - 12000 m |
| Carbon footprint | |
| Total carbon footprint (kg of CO2e) | 9090 |
| Total carbon emissions, standard deviation (kg CO2e) | 4620 |
| Carbon emissions, manufacturing (kg CO2e) | 1095.1 |
| Carbon emissions, logistics (kg CO2e) | 565 |
| Carbon emissions, energy use (kg of CO2e) | 7390 |
| End-of-life carbon emissions (kg CO2e) | 46.6 |
| Total carbon emissions, excluding the use phase (kg CO2e) | 1700 |
| PAIA version | 1.3.2, 2022 |
| Weight and dimensions | |
| Width | 200 mm |
| Depth | 680.5 mm |
| Height | 459 mm |
| Other features | |
| Data transfer rate | 6 Gbit/s |
| Bytes per sector | 512 |
